Electronic geosynthetics comprehensive strength machine
Meet the standard
GB/T16491-2022.GB/T15788-2017.GB/ T13763-2010. ASTM D4632M-a15.GB/ T2191. FZ/T01010.
CJ/T452-2014. GB18173.1-2012 and JC/T2112.
Scope of application
It is mainly used for testing and analyzing mechanical properties of metal materials and non-metal materials such as tensile, compression, bending, etc., with three closed-loop control methods of stress and strain displacement, it can calculate the maximum force, tensile strength, bending strength, compressive strength, elastic modulus, fracture elongation, yield strength and other parameters. Test and provide data according to GB and ISO, JS, ASTM, DIN and other international standards.
Technical parameters
Maximum test force 10KN
Test machine accuracy level 0.5
Test force measurement range 0.4%-100%6FS ungraded throughout
The relative error of the test force indication value is within ±0.5%
Test force resolution The maximum test force of 1/+500000 the entire resolution is unchanged
Deformation measurement range 0.2%-100%FS
The relative error of the deformation indication value is within ±0.5%
Deformation resolution 1/+500000 of the maximum deformation
Large deformation measuring range 10-800mm
The relative error of large deformation indication is within +0.5%
Large deformation resolution 0.008mm
The relative error of the displacement indication is within +0.5% of the indication
Displacement resolution 0.05um
Force control rate adjustment range 0.01-5%FS/S
The relative error of the force control rate is within +1% of the set value
Deformation rate adjustment range 0.02-5%FS/S
The relative error of deformation control rate is within +1% of the set value
Beam speed adjustment range 0.001-500mm/min
Relative error of beam speed
When the speed {<}0.01mm/min, within +1.0% of the set value
When the speed is 20.01mm/min, the set value is within ±0.2%
Constant force, constant deformation, constant displacement control range 0.5%- 100%FS
Constant force, constant deformation, constant displacement control accuracy
If the set value {<}10%FS is within +1% of the set value
When the set value is ≥10%FS, it is within +0.1% of the set value
Effective drawing space (with fixture)850mm
Effective test width 400mm
Host dimensions (L x W x H)700x510x1940(mm)
Power supply 220V±10%, 750W
The weight of the machine is about 290kg
