Carbon Black Dispersion Tester
Scope of application:
DW1431 plastic carbon black dispersion measurement system is based on a professional image acquisition system and corresponding software, through the measurement of the scale, form, and dispersion of carbon black particles, effectively evaluate the dispersion state and dispersion uniformity of carbon black particles in polyolefin geosynthetic materials, pipes, pipe fittings and mixed ingredients, pigment or carbon black materials, that is, carbon black dispersion. Carbon black is a good ultraviolet stabilizer, the best light absorber and light screen agent, which can effectively improve the anti-ultraviolet and anti-aging properties of plastic products. The content of carbon black and the dispersion of carbon black in plastic media will have a decisive effect on the UV protection, mechanical properties and life of plastic products. Through the measurement of the scale, shape and dispersion of carbon black particles, the internal relationship between these parameters and macro performance indicators such as mechanical properties, antistatic properties and hygroscopic properties can be established, which will ensure the quality of plastic materials and the production process.
New product research and development has a positive impact, while promoting the rapid improvement of the technical level of enterprises and industries.
Meet the standard:
GB/T 18251-2019.ISO/DIS 18553-1999 ASTM D5596-2003.CJ/T 234- Appendix D-2006.GB/T 17643- Appendix E-2011.etc.
Technical parameters:
Test methods Microscopy
Magnification {>}50x
Image sensor CCD camera system
The imaging resolution is 976x582 pixels
Detection range 5——150um
Rating method automatic or manual
Sample preparation method Tablet or slice method
Power supply AC 220V 50Hz
Overall dimensions 450x210x450mm
Weight 9KG
