Automatic Cross-Hatch Tester

Standards

Automotive Standards: PV 3952. Ford BN 108-03. BMW 0180. DAF KEUR 00824-401. GME 60401. GM 14829. Jaguar-Landrover TPJLR.52.00. GM N 14688

General Standards: 8350Z-SDA-9000. NES M M0159

Product Advantages

Unmatched Precision & Reliability

High-precision stepper motor and rail transmission system minimize operational noise while ensuring uniform movement and long-term durability.

Rail-guided positioning guarantees ±0.01mm accuracy, critical for repeatable cross-cut adhesion tests.

Versatile Customization

Interchangeable Weight System: Adjustable load range (5–50N) accommodates varied testing protocols, with customizable pressurization options.

Modular Fixture Design: Spin-type sample clamping ensures secure fixation without slippage; replaceable fixtures adapt to friction head dimensions for diverse test areas.

Intuitive Operability

" LCD touchscreen supports English/Chinese interfaces, enabling effortless parameter setup (stroke, speed, grid count) and real-time data monitoring.

Pre-programmed test suites align with major international standards, reducing setup complexity.

Industrial-Grade Durability

Robust construction withstands high-frequency laboratory use, maintaining calibration stability over 10.000+ test cycles.

Product Features

Advanced Control System:

LCD interface displays test progress, grid spacing (1mm/2mm options), and cutting speed (10–100mm/s adjustable).

Multi-language support enhances global usability.

Precision Engineering:

Horizontal/vertical rail transmission eliminates backlash, ensuring flawless cross-hatch pattern execution.

Quick-release friction heads simplify transitions between test configurations.

Adaptive Testing Capabilities:

Flexible fixtures integrate with imported scratch heads, enabling compliance with automotive, aerospace, and consumer goods standards.

Adjustable scratch spacing (0–2mm) caters to materials with varying surface textures.

Ergonomic Design:

Compact footprint (400x350x300mm) saves lab space while accommodating samples up to 200x150mm.

Tool-free sample mounting reduces setup time by 40% compared to traditional clamps.

Technical Parameters

Specification	Details
Load Range	5N, 10N, 20N, 50N (customizable up to 100N)
Cutting Speed	10–100 mm/s (adjustable in 1mm increments)
Grid Spacing	1mm, 2mm (0–2mm adjustable)
Sample Size	Max. 200mm (W) x 150mm (D)
Power Supply	220V/50Hz, 110V/60Hz (CE-certified)
Dimensions	400 (L) x 350 (W) x 300 (H) mm
Weight	25 kg (net)
Operating Environment	15–35°C, ≤85% RH (non-condensing)
