Textile Light and Heat Performance Tester
Product Overview
TheTextile Light and Heat Performance Testeris a multi-functional instrument designed to evaluate textile durability under combined light and thermal stress. It quantifies colorfastness, tensile strength retention, and thermal shrinkage resistance using standardized protocols for apparel, upholstery, and industrial textiles.
Type: Environmental simulation testing chamber
Compliance Standards
ISO 105-B06 (Textile lightfastness)
AATCC 133 (Thermal endurance of carpets)
GB/T 8427 (Colorfastness to artificial light)
EN ISO 105-E04 (Textile colorfastness to perspiration)
Test Methods:
ISO 105-B06 (Lightfastness)
AATCC 133 (Thermal stability)
GB/T 8427 (Colorfastness to light)
Key Metrics:
Color Change ΔE (CIELAB)
Tensile Strength Retention (%)
Thermal Shrinkage Rate (%)
Sample Size: 100×100mm (adjustable clamping)
Key Features
Dual Stress Modes:
Light + Heat:Simulates sunlight + high-temperature environments
Isolated Heat:Evaluates thermal shrinkage independently
Advanced Detection:
UV-Vis spectroscopy (400–700nm color analysis)
AI-based crack detection (5 severity levels)
Real-time thermal imaging (°C gradient mapping)
Automation:
Motorized sample rotation (0–30 RPM)
Programmable multi-stage cycles
Self-cleaning condensate drainage
Applications
Quality Control:Batch testing of outdoor fabrics
R&D:Developing UV-resistant athletic wear
Forensic Analysis:Evaluating garment degradation
Education:Training on textile degradation mechanisms
Standard Operation Workflow:
Sample Preparation: Cut to size, clamp in rotating frame
Parameter Setup: Select light/heat duration (e.g., 72h@80°C)
Testing: Initiate combined stress cycle
Analysis: Generate color loss/thermal deformation curves
Cleaning: Automated decontamination system
Safety Precautions:
Heat-resistant gloves required for sample handling
Use UV-blocking goggles during operation
Maintain 1m clearance from exhaust vents
* ISO 17025-calibrated sensors * Closed-loop cooling system (water-cooled) * NIST-traceable irradiance calibration * Includes 5-year lamp replacement warranty * Stackable design for lab/bench use**Technical Highlights**- ±0.5 ΔE color measurement accuracy (ISO 13994 validated) - 150°C sustained thermal testing - Real-time fabric strain visualization - WiFi/Bluetooth data export to cloud - CE/IECEx certified for explosive atmospheres
Technical Specifications
| Parameter | Specifications |
|---|---|
| Light Source | Xenon arc lamp (1800W, 300–800nm wavelength) |
| Irradiance | 1.12W/m²/nm @ 340nm (ISO 4892) |
| Temperature Range | 20°C–150°C (±1°C) |
| Humidity Control | 30%–90% RH (programmable) |
| Test Duration | 1–999 hours (auto-stop) |
| Power Supply | 380V/50Hz, 5kW |
| Dimensions | 1500×800×1800mm (L×W×H) |
