Filter Media Testing System
Standards
ISO 11155-1 / DIN 71460-1
Technical Data
| Measurement range (dimensions) | U-SMPS 2050: 10 – 800 nm |
| Volume flow rate | 0.48 – 5.76 m³/h (pressurized operation) |
| Power supply | 115/230 V, 50/60 Hz |
| External dimensions | Approx. 600•1.800•900 mm (W•H•D) |
| Inflow velocity | 1.3 – 16 cm/s (other specifications available upon request) |
| Differential pressure measurement | 0 – 2.500 Pa (others available upon request) |
| Media testing area | 100 cm² |
| Aerosol | Dust (e.g., SAE dust), salt (e.g., NaCl, KCl), liquid aerosols (e.g., DEHS) |
| Compressed air supply | 6 – 8 bar |
Benefits
• Simultaneous measurement of particles in both feed gas and clean gas
• Particle size measurement range: 0.2 – 40 µm
• Maximum concentration = 10⁶ particles/cm³ (undiluted)
• Internationally comparable measurement results
• Widely distributed measurement systems
• High repeatability of test methods
• Easy to use with various test aerosols, such as SAE coarse powder, NaCl/KCl, DEHS
• Maximum raw gas concentrations up to >1000 mg/m³ (ISO Fine) or >5000 mg/m³ (ISO Coarse), capable of measuring fraction separation efficiency for load testing
• Flexible filter testing software FTControl
• Pressure loss measurement, fraction separation efficiency measurement, and load measurement procedures
• Easy to operate, even untrained personnel can quickly use the equipment
• Short setup time
• Customer-initiated cleaning and calibration
• Easy use of measurement technology components – even in other applications
• Mobile setup, easy to move on casters
• Reliable operation
• Verify the functionality of individual components and the entire system during pre-delivery acceptance testing and upon delivery.
• Low maintenance
• This equipment will reduce your operating costs.
