Oil mist separation efficiency test bench - lab instrument
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
We are a professional testing instrument manufacturer offering complete laboratory testing solutions. If you need more information or wish to explore our full range of test equipment, please contact us for details and technical support.
Quality assurance and the development of filters/separators/collectors should ideally be conducted under test conditions relevant to the actual conditions encountered. Therefore, oil separators must be tested at high temperatures up to 120°C and, depending on the application type, at high pressures.
Using the modular test system HMT 1000. oil separators (e.g., for separating leaked aerosols in internal combustion engines or for separating oil mist downstream of compressors) can be characterized quickly and accurately, and successfully tested under real-world conditions via isothermal particle measurements up to 120°C:
• Staged separation efficiency
• Load/holding time
• Total separation efficiency/weight analysis
• Pressure loss
Due to the modular layout, individual components of the test bench, such as the high-resolution heated light scattering spectrometer, the heated dilution system KHG 10 D, and the heated aerosol generator PLG 2100. can be easily removed from the HMT 1000 and used for other applications, such as direct measurements on the engine.
At the heart of the HMT 1000 is the light scattering spectrometer, which is used to simultaneously and independently measure particle size and particle number (and thus concentration). With the Promo® 1000 H, very fast, clear, reproducible, and isothermal measurements are possible.
Standard
GB/T 6165-2021
Technical parameters
| Measurement range (size) | 0.18 – 40 µm |
| Volume flow rate | 1 – 25 Nm3/h, 1 – 85 Nm3/h (Other specifications available upon request) |
| External dimensions | Approximately 1.600•2.000•800 mm (H•W•D) |
| Differential pressure measurement | 0 – 5.000 Pa (ande auf Anfrage) |
| Aerosol concentration | Up to 107 particles/cm3. equipped with 2 KHG 10 D |
| Compressed air supply | 6 – 8 bar |
