Iso 17493 Hot Air Circulation Oven
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
Hot Air Circulation Oven has a fully welded stainless steel frame structure for curing, drying, and sterilizing powders, granules, herbs, or fruit. Whether in R&D, mass production, or quality control;Hot Air Circulation Oven ensures precise hot airflow in all the oven trays.
Hot air circulation oven has energy-efficient axial blowers and heating systems. the hot air circulating oven saves on cost and ensures uniform drying and curing. hot air circulation pharmaceutical ovens guarantee unlimited functionalities with both standard and custom designs available. Baking, drying, tempering in electroplating, plastics, chemicals, food, printing, electronics, hardware, pharmaceuticals, roasted tea, etc.
Standards:
ISO 17493，ASTM F2894
Product Parameters：
| Power | 1 phase 220V 50Hz | Cable Port | External Power |
| Interior Size | 50*60*50cm(W*H*D) | Exterior Size | 69*110*64cm(W*H*D) |
| (W*H*D) | (W*H*D) | ||
| Customized Size | Acceptable | Control Method | PID ,PID automatically adjust the output |
| Temp Control Fluctuation | ± 1.5ºC | Temperature Range | RT+10ºC~300ºC |
| Accuracy | ±0.5ºC | Temperature Resolution | 0.1 |
| Temperature Uniformity | ±2ºC | Power | 4.8KW |
| Key Set of | Resolution 0.1 ºC | Protection Device | Motor overload protection |
| Data Input | ntegration time(IT): | Buzzer | |
| 0~3600s | Fault indicator | ||
| Derivative time(DT): | No fuse protection switch | ||
| 0~900s | |||
| Built-in timer function | |||
| Heating Up Time | RT~160ºC about 28min | ||
| (NO-load) | |||
| Temp Controller | The microcomputer automatically calculus controller | ||
| Chamber Materials | 1.Inner chamber materials:SUS stainless steel plate | ||
| 2.External chamber materials:Special steel, galvanized anti-rust treatment, outside with Advanced wear-resistant resin paint coating. | |||
| 3.Insulation material: aluminum silicate glass wool | |||
| 4.The clapboard Material: Stainless Steel | |||
| 5.Stainless steel electric heater Material: fin heat pipe type | |||
| 6.Time control: 0 ~ 999H/M/S adjustable. | |||
| 7.The rmometry body: T thermocouple | |||
| Air Supply Method | Galvanized wind wheel forced air circulation, the left and right into the return air to ensure uniformity of temperature, not | ||
| cause direct damage of high temperature ,when open the door. | |||
| Use of The Environment | Allowable temperature range of 0 ~ 35 ºC | ||
Introduction&Applicable Industries:
Drying Oven can provide a stable test space for pre-heating, drying, and changes in physics and chemistry testing.
It supplies a precision temperature controller with high stability of platinum resistance to temperature that makes temperature well-distribution.
This machine can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing.
