fatigue testing machine - lab instrument
We are a professional testing instrument manufacturer offering complete laboratory testing solutions. If you need more information or wish to explore our full range of test equipment, please contact us for details and technical support.
Standards
- ISO 5402: Leather physical testing – Flex tester method for adhesion and strength analysis.
- SATRA TM55: Seam fatigue testing for footwear, ensuring stitching integrity under cyclic stress.
- ASTM D6193: Loop strength testing for leather goods, critical for accessories like belts and bags.
- GB/T 3903.32: Chinese national standard for footwear seam fatigue resistance.
- EN 13520: Flexometer testing for coated fabrics, validating bonding durability in automotive interiors.
Product Advantages
- Multi-Station Efficiency: Simultaneously test up to 4 samples, accelerating QC workflows and reducing testing time.
- Precision Flex Simulation: Adjustable stroke frequency (100–300 cycles/min) and bending angles (0–90°) replicate real-world wear patterns.
- Versatile Applications: Ideal for footwear, automotive upholstery, fashion accessories, and industrial textiles.
- User-Centric Design: PLC-based touchscreen control with programmable cycles, angles, and loads for automated testing.
- Data-Driven Insights: Built-in cycle counter and failure detection for objective pass/fail criteria (e.g., stitch breakage thresholds).
- Compact Durability: Robust construction with a 120W motor and 50N load capacity for heavy-duty use in industrial labs.
Product Features
- Quad-Testing Stations: Independent clamping mechanisms for parallel evaluation of seams, loops, or bonded joints.
- Customizable Testing Modes:
- Seam Fatigue: SATRA/ISO-compliant bending cycles (e.g., 50,000 cycles for footwear uppers).
- Loop Strength: ASTM-standard tension tests for leather accessories.
- Adhesion Integrity: EN 13520-compliant coating delamination analysis.
- Advanced Control System:
- 7-inch touchscreen with preset protocols for footwear, automotive, and fashion industries.
- Adjustable load cell (0–50N) for tension/compression testing.
- Fail-Safe Mechanisms: Auto-stop function upon seam failure or cycle completion, with real-time data logging.
- Ergonomic Design: Quick-release clamps for rapid sample mounting and tool-free angle adjustments.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Stations | 1–4 (simultaneous operation) |
| Stroke Frequency | 100–300 cycles/min (adjustable) |
| Bending Angle | 0–90° (customizable) |
| Load Capacity | 0–50N (adjustable) |
| Sample Dimensions | 150 × 30 mm (standard) |
| Control System | PLC with touchscreen (programmable cycles, angles, loads) |
| Power Supply | 220V/50Hz, 120W |
| Dimensions | 600 (L) × 450 (W) × 500 (H) mm |
| Net Weight | 45 kg |
| Cycle Counter | Digital (1–999,999 cycles) |
