Rubber hose wear testing machine

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Rubber Hose Wear Testing Machine is designed to evaluate the abrasion resistance of hydraulic hoses and other similar hoses with fabric or steel wire reinforcement and a smooth, flat surface. It can also be applied to other pipes, tubing, and flat plates to determine their wear resistance. The tester is widely used by hose manufacturers, research institutes, and quality inspection units to ensure product durability and reliability under specific working conditions.

Applications

(1) Hydraulic hose testing: Measuring wear resistance of hoses with fabric or steel wire reinforcement.

(2) Other hose testing: Evaluating wear properties of rubber hoses for industrial or automotive use.

(3) Pipe and plate testing: Determining abrasion resistance of rubber or polymer-based pipes and flat plates.

(4) Quality control: Ensuring products meet required durability and reliability standards.

(5) Scientific research: Assessing material performance in laboratory studies and R&D projects.

Standards

(1) GB/T 12721-2007 — Determination of abrasion resistance of rubber hose outer coating

(2) ISO 6945:1991 — Rubber hose cladding — Determination of abrasion resistance

(3) KS M ISO 6945-2013 — Determination of abrasion resistance of the outer coating of rubber hoses

(4) EN ISO 6945-1996 — Determination of the abrasion resistance of rubber hose outer coatings

(5) DS/ISO 6945-1984 — Determination of wear resistance of rubber hose cladding

Advantages

(1) Accurate wear testing: Evaluates hose and pipe abrasion resistance under controlled conditions.

(2) Standard compliant: Meets national and international testing standards (GB, ISO, EN, KS).

(3) Versatile application: Suitable for hoses, pipes, and flat rubber or polymer plates.

(4) Quantitative results: Provides precise measurement of wear resistance for quality control and R&D.

(5) Durable design: Built to withstand repeated testing cycles in laboratories and production environments.

Technical Parameters

ItemSpecification
Test station 1 or more stations for sample placement
Weight load 50 N, 100 N, 150 N (adjustable per test requirements)
Test stroke 5–100 mm (adjustable)
Test speed 5–120 times/min (adjustable)
Mandrel length 150 mm
Shaft diameter 5, 8, 10, 13, 16, 19, 22, 25, 32, 38, 45, 51 mm (customizable)
Reciprocating frequency 1.25 Hz (45 RPM)
