Fabric Negative-ion Concentration Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Applications
Functional Textile R&D: Assesses air-purifying, health-enhancing, and antimicrobial fabrics.
Quality Control: Verifies compliance with negative-ion standards for medical textiles, bedding, and apparel.
Certification Laboratories: Provides data for GB/T 30128-2013 certification.
Standards
GB/T 30128-2013: Textiles – Test and Evaluation of Negative Ion Generation
Features
Dual Friction Disc Design:
Upper Static Disc: Diameter 100 ±0.5 mm (fixed).
Lower Dynamic Disc: Diameter 200 ±0.5 mm (rotating at 93 r/min).
Capacitive Ion Sensor: High-sensitivity detection of activated negative ions.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Automatic (PLC) |
| Ion Collection Method | Capacitive Suction (Mobility >0.15 cm²/(V·s)) |
| Measurement Range | Range 1: 0–20.000 units/cm³ Range 2: 0–200.000 units/cm³ Range 3: 0–2.000.000 units/cm³ |
| Resolution | 10 units/cm³ |
| Friction Disc Speed | 93 ±1 r/min (Adjustable) |
| Applied Pressure | 7.5 ±0.2 N |
| Test Chamber Size | 300 ±2 mm × 560 ±2 mm × 210 ±2 mm |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 600 mm × 620 mm × 520 mm |
| Net Weight | 55 kg |
