Safety Harness Test Rubber Dummy
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The safety harness test dummy is used for dynamic load, overall static load, and overall slip testing of harness systems. By simulating human body shape and weight, it ensures that various safety harnesses meet strength and performance requirements during use. It is an important testing tool for safety harness manufacturers, inspection agencies, and construction safety evaluation.
Application
Performance testing of fall protection safety harness systems
Performance evaluation of harness systems for guardrail work
Verification of area-restricted safety harness systems
Rescue harness performance testing
Dynamic and static load testing of safety harnesses
Safety inspection for construction and industrial high-altitude work
Verification of safety harness products in testing laboratories and inspection agencies
Standards
GB6095-2021 Fall Protection Safety Harness
GB/T6096-2020 Fall Protection Safety Harness System Performance Test Methods
GB6095-2009 Safety Harness
GB/T6096-2009 Safety Harness Test Methods
Product Specifications
| Item | Technical Parameters |
|---|---|
| Dummy Weight | 100 ± 2 kg, 136 ± 2 kg |
| Surface Hardness | >90 HD |
| Rubber Thickness | ≥40 mm |
| Number of Attachment Points | 4 (1 each for left and right hands, 1 head, 1 crotch) |
| Attachment Material | 304 Stainless Steel M16 Lifting Rings |
| Key Dimensions | Shoulder width: 483 mm, Hip width: 400 mm, Leg circumference: 150 mm, Neck circumference: 150 mm, Leg spacing: 50 mm |
| Exterior Material | Molded as a single internal structure, integrated outer rubber layer |
| Surface | Smooth transitions to avoid metal contact interfering with tests |
Product Features
Integrated one-piece mold design with smooth surface, simulating human body shape
Adjustable hardness at different body parts to simulate varying load-bearing properties
Full-body rubber construction avoids metal interference with harness testing
Equipped with four high-strength M16 stainless steel lifting rings for various experimental connections
Dimensions comply with GB/T6096-2020 standard
Suitable for dynamic load, static load, and fall slip experiments
