Flatbed Ironing Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Flatbed Ironing Tester is a laboratory-grade instrument designed to simulate real-world ironing conditions for evaluating fabric thermal performance. It provides precise assessment of crease recovery, heat resistance, dimensional stability, shrinkage behavior, and surface appearance changes. Ideal for quality control, production inspection, and textile R&D, it delivers consistent, repeatable, and standard-compliant test results.
Application
Suitable for a wide range of textile and material evaluations, including:
Apparel fabrics (cotton, polyester, wool, nylon, spandex, blends)
Home textiles (bedding, upholstery, curtains, table linens)
Industrial fabrics (automotive interiors, filtration materials, protective garments)
Functional textiles (FR fabrics, coated fabrics, waterproof/breathable laminates)
Laminated materials (PU/PVC synthetic leather, soft-touch coatings, printed laminates)
Finished fabrics requiring wrinkle-resistant, shrink-resistant, or heat-set performance
Smart and sensitive textiles requiring controlled thermal tests
QC laboratories, inspection institutes, textile mills, and educational institutions
Forensic analysis of heat-damaged textiles and garment care research
Features
(1) Realistic ironing simulation – Accurately reproduces domestic and industrial ironing conditions.
(2) Multi-function testing – Supports crease recovery, shrinkage, and heat-setting evaluations.
(3) Touchscreen control – 7-inch display with programmable test sequences.
(4) Stable & repeatable performance – Uniform heating and reliable pressure control.
(5) Built-in data logging – Test parameters can be exported for documentation.
(6) Enhanced safety system – Overheat protection and interlock safety switch.
(7) Low-maintenance design – Easy-clean platform and durable heating system.
Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | Ambient +20 °C to 300 °C |
| Heating Rate | 10 °C/min (programmable) |
| Temperature Uniformity | ±2 °C across test area |
| Pressure Control | 0.5–5 kPa adjustable |
| Test Area | 300 × 300 mm heated flatbed |
| Cooling System | Forced-air cooling (30 °C recovery in 5 min) |
| Power Supply | 220 V / 50 Hz, 1.5 kW |
| Dimensions | 600 × 500 × 1200 mm (W×D×H) |
| Weight | 45 kg |
| Control System | 7-inch touchscreen with programmable sequences |
Send product request
