Conduit Bending Test Machine

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Conduit Bending Test Machine is designed to evaluate the bending and torsion resistance of photovoltaic (PV) module conduits. By applying specified weights to the conduit and rotating it at a controlled speed, the system simulates mechanical stresses that conduits may encounter during transportation, installation, and operational use. This allows accurate assessment of conduit reliability, durability, and structural integrity.

Standards

IEC 61730-2:2004 – Photovoltaic (PV) Module Electrical Safety Requirements

Parameters

ItemTechnical Parameter
Controller Frequency Range 0–120 Hz
Spindle Rotational Speed N rev./min = Frequency Hz / 60 (e.g., 60 Hz → 1 rev./min)
Timer Range 1–9999 s
Power Supply Single-phase AC 220 V, 100 W
Conduit Outer Diameter & Weight 13–25 mm → 220 N; 26–50 mm → 330 N; 51–100 mm → 490 N
