Large-Scale Composite Salt Spray Test Chamber
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
TheLarge-Scale Composite Salt Spray Test Chamberis a professional environmental simulation instrument designed to replicate complex corrosion conditions, including high-salt, high-humidity, and temperature-humidity cycles. You can use it to test full vehicles, large components, or batch samples for corrosion resistance, providing reliable data for product development, quality control, and durability verification in automotive, aerospace, and defense industries.
Standards
GMW 14872 Simulating the Corrosion Resistance of Automotive Components in Alternating Salt Spray, Humidity, and Dry Environments
GJB 150.11A Salt Spray Testing for Military Equipment
GB/T 10125-2021 Artificial Atmosphere Corrosion Testing—Salt Spray Test
ASTM B117 Simulating Complex Corrosion Environments (Marine, Chemical, etc.) to Evaluate Material or Coating Corrosion Resistance
ISO 9227:2022 Corrosion tests under artificial climatic conditions—Salt spray test
ASTM G85 Standard Test Method for Modified Salt Spray Test
GB/T 2423.17 Salt spray test for electrical and electronic products
GB/T 2423.18 Combined salt spray test
Parameters
| Item | Specifications | Features |
|---|---|---|
| Working Chamber Dimensions | 10–18 m (L) × 3–5 m (W) × 3–4 m (H) | Customizable, suitable for whole vehicles or large components |
| Salt Spray Modes | Switchable between NSS/ASS/CASS modes | Meets different corrosion intensity requirements |
| Temperature Range | -40°C ~ 150°C (higher in some expanded models) | Supports combined temperature-humidity and salt spray tests |
| Salt Spray Settling Rate | 1–2 mL/80 cm²/h, digitally displayed and automatically adjustable | Complies with GB/T 10125. ASTM B117. and other standards |
| Safety Protection | Over-temperature protection, water shortage alarm, leakage protection | Prevents sample damage |
