Double-Head Abrasion Tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Double-Head Abrasion Tester is a motor-driven wear testing instrument designed to evaluate the abrasion resistance of paper, cardboard, and printed materials. Equipped with dual electric brushes and adjustable weights, it can perform dry abrasion, wet abrasion, color transfer, and specialized friction tests to assess ink durability and adhesion. The device offers multiple speed settings and preset counting functions, complying with ASTM D-5264 standards, making it suitable for research, quality control, and standardized laboratory testing.

Applications

Testing ink abrasion resistance on printed materials

Evaluating surface wear performance of paper and cardboard

Performing dry abrasion, wet abrasion, and transfer friction tests

Supporting product development and production quality control

Conducting standardized testing in teaching and research laboratories

Standards

ASTM D-5264-92: Standard Test Method for Abrasion Resistance of Printed Matter

GB/T 7705-2008: National Standard for Offset Decorative Printed Matter

Technical Specifications

ItemParameter
Power Supply 220V / 50-60Hz / Single Phase / 2A
Dimensions 15 × 15 × 12 inches
Weight Gross 42 lbs
Speed Settings Speed 1: 21 rpm
Speed 2: 42 rpm
Speed 3: 85 rpm
Speed 4: 106 rpm
Count Range 0–999 cycles (presettable)
Slider Weights Standard: 2 lbs (0.9 kg), 4 lbs (1.8 kg)
Optional: 20 N weight
Display LCD
Functions Dry abrasion, wet abrasion, wet smear or transfer, functional friction tests
Automatic Features Auto power-off, end-of-test notification

Features

Four adjustable speeds to accommodate various abrasion testing requirements

Dual-head design allows simultaneous testing of two samples, improving efficiency

Supports dry, wet, and specialized friction tests, providing versatile testing options

Built-in preset counting ensures accurate and repeatable results

Supports optional weights for flexible load adjustment

LCD display offers intuitive operation and easy data reading

High-speed mode (106 rpm) enables fast wear testing
