Double-Head Abrasion Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Double-Head Abrasion Tester is a motor-driven wear testing instrument designed to evaluate the abrasion resistance of paper, cardboard, and printed materials. Equipped with dual electric brushes and adjustable weights, it can perform dry abrasion, wet abrasion, color transfer, and specialized friction tests to assess ink durability and adhesion. The device offers multiple speed settings and preset counting functions, complying with ASTM D-5264 standards, making it suitable for research, quality control, and standardized laboratory testing.
Applications
Testing ink abrasion resistance on printed materials
Evaluating surface wear performance of paper and cardboard
Performing dry abrasion, wet abrasion, and transfer friction tests
Supporting product development and production quality control
Conducting standardized testing in teaching and research laboratories
Standards
ASTM D-5264-92: Standard Test Method for Abrasion Resistance of Printed Matter
GB/T 7705-2008: National Standard for Offset Decorative Printed Matter
Technical Specifications
| Item | Parameter |
|---|---|
| Power Supply | 220V / 50-60Hz / Single Phase / 2A |
| Dimensions | 15 × 15 × 12 inches |
| Weight | Gross 42 lbs |
| Speed Settings | Speed 1: 21 rpm Speed 2: 42 rpm Speed 3: 85 rpm Speed 4: 106 rpm |
| Count Range | 0–999 cycles (presettable) |
| Slider Weights | Standard: 2 lbs (0.9 kg), 4 lbs (1.8 kg) Optional: 20 N weight |
| Display | LCD |
| Functions | Dry abrasion, wet abrasion, wet smear or transfer, functional friction tests |
| Automatic Features | Auto power-off, end-of-test notification |
Features
Four adjustable speeds to accommodate various abrasion testing requirements
Dual-head design allows simultaneous testing of two samples, improving efficiency
Supports dry, wet, and specialized friction tests, providing versatile testing options
Built-in preset counting ensures accurate and repeatable results
Supports optional weights for flexible load adjustment
LCD display offers intuitive operation and easy data reading
High-speed mode (106 rpm) enables fast wear testing
