Dry Friction and Wear Tribometer (Value Engineered Tribometer)

Get a quote:

Email:info@qinsun-lab。com

Web: qinsun-lab.com

The Dry Friction and Wear Tribometer is a value-engineered, multi-functional testing instrument designed to study the friction and wear behavior of materials under dry or self-lubricated conditions. You can precisely control load, speed, and temperature through pneumatic loading, while an air-bearing friction assembly and touch-screen PC interface provide accurate measurement and data logging. The instrument supports online or offline wear measurement and is suitable for both research and industrial laboratory evaluation of material tribological performance.

Standards

You can perform tests in accordance with the following international standards:

(1) ASTM D3702 – Standard Test Method for Wear Rate of Materials in Self-Lubricated Rubbing Contact Using a Thrust Washer Testing Machine

(2) ASTM G99 – Standard Test Method for Wear Testing with a Pin-on-Disc Apparatus

Note: The instrument structure and control logic are consistent with internationally recognized pin-on-disc and thrust washer test devices, ensuring compliance with relevant research and benchmark testing requirements.

Parameters

ParameterSpecification
Thrust Washer Test Compliant with ASTM D3702
Pin-on-Disc Test Compliant with ASTM G99
Pin Track Radius 10–35 mm
Pin Dimensions Ø8 mm × 15 mm
Test Disc Diameter Maximum 75 mm
Load Range 20–750 N (@6 bar air pressure)
Load Application Pneumatic
Load Measurement Pressure sensor
Load Control Manual precision regulator
Friction Measurement Databeam strain gauge sensor
Torque Reaction Support Air bearing
Temperature Range Ambient to 200°C
Heating Power 550 W
Temperature Sensor K-type thermocouple
Speed Range 30–1,800 rpm
Motor 1.5 kW AC vector motor
Control & Data Acquisition Touch-screen PC interface
Data Export USB
