Dry Friction and Wear Tribometer (Value Engineered Tribometer)
Get a quote：
Email：info@qinsun-lab。com
Web: qinsun-lab.com
The Dry Friction and Wear Tribometer is a value-engineered, multi-functional testing instrument designed to study the friction and wear behavior of materials under dry or self-lubricated conditions. You can precisely control load, speed, and temperature through pneumatic loading, while an air-bearing friction assembly and touch-screen PC interface provide accurate measurement and data logging. The instrument supports online or offline wear measurement and is suitable for both research and industrial laboratory evaluation of material tribological performance.
Standards
You can perform tests in accordance with the following international standards:
(1) ASTM D3702 – Standard Test Method for Wear Rate of Materials in Self-Lubricated Rubbing Contact Using a Thrust Washer Testing Machine
(2) ASTM G99 – Standard Test Method for Wear Testing with a Pin-on-Disc Apparatus
Note: The instrument structure and control logic are consistent with internationally recognized pin-on-disc and thrust washer test devices, ensuring compliance with relevant research and benchmark testing requirements.
Parameters
| Parameter | Specification |
|---|---|
| Thrust Washer Test | Compliant with ASTM D3702 |
| Pin-on-Disc Test | Compliant with ASTM G99 |
| Pin Track Radius | 10–35 mm |
| Pin Dimensions | Ø8 mm × 15 mm |
| Test Disc Diameter | Maximum 75 mm |
| Load Range | 20–750 N (@6 bar air pressure) |
| Load Application | Pneumatic |
| Load Measurement | Pressure sensor |
| Load Control | Manual precision regulator |
| Friction Measurement | Databeam strain gauge sensor |
| Torque Reaction Support | Air bearing |
| Temperature Range | Ambient to 200°C |
| Heating Power | 550 W |
| Temperature Sensor | K-type thermocouple |
| Speed Range | 30–1,800 rpm |
| Motor | 1.5 kW AC vector motor |
| Control & Data Acquisition | Touch-screen PC interface |
| Data Export | USB |
