Pin-on-Disc Machine
Get a quote：
Email：info@qinsun-lab。com
Web: qinsun-lab.com
The Pin-on-Disc Machine is a classic tribological testing instrument designed for studying friction, wear, and contact behavior of materials under controlled sliding conditions. You can use a pin or ball sample loaded vertically against a rotating horizontal disc to simulate real-world sliding contacts. The instrument features a pneumatic loading system that minimizes inertia effects on friction and wear response, making it suitable for dry, lubricated, and extended contact-type testing.
Standards
You can perform tests according to these procedures:
(1) ASTM G99 – Pin-on-Disc wear testing method.
(2) ASTM F732 – Reciprocating pin-on-plate friction test method.
(3) DIN 50324 – Methods for testing friction and wear.
(4) ISO/DIS 7148-2 – Guidelines for pin-on-disc friction and wear testing.
Parameters
| Parameter | Specification |
|---|---|
| Rotational Speed | 20 – 2,000 rpm |
| Equivalent Sliding Velocity | 0.05 – 8 m/s |
| Test Track Radius | 0 – 35 mm |
| Load Method | Pneumatic / Weight loading |
| Pneumatic Load Range | 25 – 1,000 N |
| Weight Load Range | 5 – 100 N |
| Cyclic Load Amplitude | Up to 50% of set load |
| Cyclic Load Form | Sine / Triangle |
| Cyclic Load Frequency | Max 1 Hz |
| Friction Force Measurement | 0 – 50 N / 0 – 1,000 N |
| Wear Measurement | LVDT displacement sensor |
| Wear Measurement Range | 0 – 2.5 mm |
| Wear Resolution | |
| Contact Potential | 40 mV DC |
| Temperature Measurement | K-type thermocouple |
| Disc Sample | Ø75 mm × 8 mm |
| Pin Sample | Ø8 mm × 35–68 mm |
| Ball Sample | Ø6 mm |
| Drive Motor | 2.2 kW AC vector motor |
| Control & Data Acquisition | Software + USB interface |
