Probe-Type Material Surface Wear Scar Tester

The Probe-Type Material Surface Wear Scar Tester is a precision device designed for high-accuracy measurement of wear scars formed on material surfaces after friction and wear tests. It can automatically measure scar width and depth, calculate wear volume, and display two-dimensional profile maps for intuitive visualization of wear morphology. The instrument quantitatively evaluates material surface wear and abrasion resistance. Additionally, it can function as a step gauge to measure coating thickness and surface profiles, making it widely applicable in material research, coating evaluation, and industrial quality control.

Application

Measurement of wear scars and assessment of abrasion resistance for metals, ceramics, plastics, and composite materials.

Coating thickness measurement and surface profile analysis.

Analysis of wear scars after friction and wear experiments and collection of experimental research data.

Quality control and verification in industrial manufacturing and material inspection processes.

Standards

GB/T 3960-2016 Test Methods for Sliding Friction and Wear of Plastics

ISO 20502:2016 Test Method for Coating Scratch Resistance

ASTM D7027 Coating Scratch Hardness and Wear Scar Measurement

JB/T 8554-1997 Automatic Scratch Measurement Method for Coating Adhesion (can be used with wear scar analysis)

Parameters

ParameterTechnical Specification
Wear Scar Scanning Mode Automatic
Probe Vertical Resolution 0.02 μm
Wear Volume Test Force Range ≤40 g
Probe Vertical Measurement Range ±0.5 mm (customizable)
X-Axis Movement Range 0–50 mm
Y-Axis Movement Range 0–25 mm
Z-Axis Movement Range 0–50 mm
Sample Plate Size Φ76 mm
Instrument Main Unit Dimensions 230 × 300 × 260 mm
Instrument Main Unit Weight 10 kg
Power Supply 210–235 V, 50–60 Hz, 2500 W
Workbench Size 1500 × 750 × 800 mm (user-provided)

Features

High-precision measurement: vertical resolution of 0.02 μm ensures accurate detection of fine wear scars.

Automatic scanning and data processing: measures scar width, depth, and wear volume, generating two-dimensional profile maps.

Wide measurement range: Z-axis ±0.5 mm, X/Y axes movable to accommodate different sample sizes.

Multifunctional application: can function as a step gauge for coating thickness and surface profile measurements.

Data storage and display: real-time graphical display for research analysis and experimental data archiving.

User-friendly operation: easy sample installation, suitable for laboratory and industrial use.
