AAA-Class Solar Simulator
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
AAA-Class Solar Simulator is a high-performance device designed to replicate sunlight for testing and research purposes. It can simulate key parameters of solar irradiation, including intensity, spectrum, color, uniformity, and temporal stability. The simulator is essential for evaluating solar cells, solar water heaters, and other photovoltaic products. The “AAA” designation represents the highest international standard ratings for spectral match, irradiance uniformity, and temporal stability, ensuring highly accurate and reproducible results in material science, photovoltaics, and environmental testing applications.
Application
The AAA-Class Solar Simulator is widely applied across various research and testing scenarios, including:
Photovoltaic Testing:
Efficiency measurements of solar cells (I-V curves, quantum efficiency)
Module aging and reliability tests (PID, LID effects)
Materials Research:
Evaluation of photocatalytic materials
Performance testing of photothermal conversion materials
Environmental Simulation:
Accelerated weathering tests for spacecraft components
UV aging tests for automotive coatings
The simulator supports a wide range of solar energy products, material studies, and environmental simulation experiments.
Standards
The simulator conforms to key international standards, including:
(1) IEC 60904-9:2020 – Photovoltaic devices – Part 9: Solar simulator performance requirements
(2) ASTM E927 – Classification of solar simulators for photovoltaic device testing
(3) JIS C8912 – Solar simulators for crystalline silicon photovoltaic cells and modules
Parameters
| Item | Specification |
|---|---|
| Wavelength range | 300–1100 nm (AM0), 400–1100 nm (AM1.5G) |
| Spectral irradiance distribution | Matches AM1.5G standard within ±25% for AAA class |
| Irradiance non-uniformity | ≤2% over effective test area (≥100 mm diameter) |
| Temporal stability | Short-term ≤0.5%, Long-term ≤2% (Class A) |
| Light sources | Xenon lamp, LED array, halogen lamp with filter |
| Effective test area | 50×50 mm to 200×200 mm (adjustable) |
| Light collimation | Optional parallel light for space simulation experiments |
| Irradiance intensity | Adjustable up to 1000 W/m² standard test conditions |
| Power supply | AC 220V, 50/60 Hz (dependent on configuration) |
| Control system | Real-time feedback for irradiance stability |
| Uniformity control | Integrating sphere or homogenizer system |
| Temperature stability | Maintains consistent irradiance across temperature variations |
| Spectral calibration | AM1.5G filter and software-based spectral correction |
| Control interface | Integrated software for spectral calibration, irradiance adjustment, and multi-region testing |
Features
Simulates full solar spectrum, including UV, visible, and near-infrared bands
AAA-class spectral match, irradiance uniformity, and temporal stability
Multiple light source options: xenon lamp, LED array, halogen lamp with filters
Optical homogenizers ensure uniform illumination over the effective test area
Real-time feedback control maintains irradiance stability during long tests
Integrated software allows automated spectral calibration, multi-zone testing, and irradiance adjustment
Optional collimated beam configuration for space environment simulations
Effective area adaptable to different sample sizes, up to 200×200 mm
