Building material monomer combustion tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Monomer building materials combustion equipment is used to determine the construction materials or products (not including floor materials and the EC resolution of 2000/147 / EC (it and pointed out that the products) in the monomer (SBI) combustion test fire response performance of the size of test device. The device USES the computer interface to control the test equipment directly, which greatly saves the manpower and material resources.
Application:
This instrument belongs to the building combustion performance grading test instrument. It can be used to assess the grade of building materials.
The gas circuit of the whole equipment is good.
High degree of automation. Easy to learn.
System modular design, easy to maintain.
Computer data acquisition system can automatically record the oxygen concentration and the concentration of carbon dioxide, smoke density, flue temperature, environment temperature and humidity (data collection interval 3 s), can be automatically calculated the heat release quantity, THR600s, index and smoke production rate of gas production rate.
Standards:
GB 8624-2012: building materials and product combustion performance rating
GB/T 20284-2006: "single combustion test for building materials or products"
EN 13823:2002 :"building products fire response - single combustion test method for building products without paving materials"
ISO – Plastics—Smoke Generation, Part 2: Single-Chamber Test for Optical Density
ASTM E662-2014 – Standard Test Method for Specific Optical Density of Smoke Generated by Solid Materials
BS 476-6:1989 – Fire Tests on Building Materials: Method of Test for Fire Propagation
EN 13501-1:2007 – Fire Classification of Construction Products and Building Elements, Part 1: Reaction to Fire
Parameters:
| Item | Specification |
|---|---|
| Combustion laboratory size | 3000mm * 3000mm * 2800mm |
| Outline dimensions of smoke pipe in combustion chamber | 5200mm * 3000mm * 1800mm |
| Control box outline dimension | 800mm * 1200mm * 1500mm |
| Smoke extraction speed | 0.50m³/s ~ 0.65m³/s |
| Temperature measurement device | Imported K-type armored thermocouple, 3mm diameter |
| Temperature measurement precision | ±0.5℃ |
| Accuracy of pressure sensor | (Not specified) |
| Test time | 1560s; Time recording system accuracy: 0.1s |
| Oxygen analysis (paramagnetism) range | (0-25)% |
| Oxygen analysis response time | <12s |
| Oxygen analysis noise drift (within 30min) | ≤100 x 10⁻⁶ |
| Oxygen analysis data collection and output resolution | >100 x 10⁻⁶ |
| Carbon dioxide (IR) measurement range | (0-10)% |
| Carbon dioxide measurement linearity | >1% of full range |
| Carbon dioxide data collection and output resolution | >100 x 10⁻⁶ |
| Detector color standard accuracy | ±5% |
| Detector output linearity (transmittance) | <3% |
| Detector absolute penetration rate | <1% |
| Test environment temperature | (10 ~ 30)℃ |
| Control cabinet power supply voltage | AC 220V 50HZ |
| Maximum equipment power | 11.5KW |
| Alarm condition | Flue gas pipeline temperature >400℃ |
| Sample adjustment status temperature | (21-25)℃ |
| Sample adjustment status humidity | (45-55)% RH |
| Distance of test piece from opposite side | 2100mm |
