Fire resistance testing furnace for construction industry vertical type
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
Vertical Building Elements
Fire resistance testing of non-loadbearing vertical partitions, walls, and separation elements.
Fire Doors and Fire Shutters
Performance evaluation of doors, rolling shutters, and related assemblies under standard fire exposure.
Building Fire Safety Evaluation
Verification of fire resistance performance for construction materials and assemblies used in buildings.
Fire Testing Laboratories and Certification Bodies
Standardized testing for product certification, compliance verification, and research applications.
Standards
The equipment complies with the following standards:
(1) GB/T 9978.4-2008 – Fire Resistance Tests — Elements of Building Construction — Part 4: Specific Requirements for Loadbearing Vertical Separating Elements
(2) GB/T 9978.8-2008 – Fire Resistance Tests — Elements of Building Construction — Part 8: Specific Requirements for Non-loadbearing Vertical Separating Elements
(3) GB/T 7633-2008 – Fire Resistance Test Methods for Doors and Shutters
(4) ISO 834 – Fire Resistance Tests — Elements of Building Construction
(5) EN 1363 – Fire Resistance Tests for Building Elements
Parameters
| Item | Specification |
|---|---|
| Number of Burners | 12 proportional flat-flame burners (6 on each side, 5 m furnace length) |
| Operating Temperature | Maximum test temperature 1250 °C |
| Design Temperature | 1350 °C |
| Combustion Mode | Low-speed proportional flat-flame diffusion combustion |
| Gas & Air Pressure | ≤ 4000 Pa |
| Flame Length | ≤ 500 mm |
| Furnace Temperature Measurement Points | 9 points |
| Thermocouple Sleeve Extension | ≥ 25 mm |
| Temperature Accuracy | < ±15 °C |
| Fuel Gas | Liquefied petroleum gas |
| Equipment Dimensions | 3 m (W) × 3 m (L) × 1.25 m (H) |
| Power Supply | AC 380 V, 70 kW |
| Equipment Weight | Approx. 5 t |
Accessories
(1) Proportional flat-flame burners
(2) Gas solenoid valves and proportional valves
(3) Combustion air blower with frequency inverter
(4) Gas pressure regulators and filters
(5) Exhaust duct with refractory brick structure
(6) High-temperature exhaust fan with inverter
(7) PLC-based control system
(8) Computerized data acquisition and monitoring system
