Plastic Friction and Wear Testing Machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
This machine complies with the standard GB/T3960-2016: Methods for Testing Sliding Friction and Wear of Plastics. It is suitable for determining the sliding friction and wear performance of plastics and plastic-based composites, and can also measure frictional force and coefficient of friction of the test samples. The instrument features a color touch screen for control, data processing, and a micro-printer.
Application
Evaluate friction and wear properties of plastic materials under various loads and speeds.
Test plastic components used in automotive, electronics, and industrial machinery.
Support material development, quality control, and durability assessment.
Simulate real-world mechanical contact conditions to predict performance and lifespan.
Features
(1)Wide Load Range: Can test plastics under low to high loads for versatile applications.
(2)Adjustable Speed and Stroke: Allows precise control of sliding speed and motion distance.
(3)High-Precision Sensors: Measures friction force and wear accurately.
(4)Versatile Test Modes: Supports reciprocating, rotational, and block-on-ring testing configurations.
(5)Data Acquisition System: Real-time monitoring and recording of friction and wear data.
(6)Durable Construction: Rigid frame minimizes vibration and ensures repeatable results.
Parameters
| Parameter | Specification |
|---|---|
| Sample Size | (30 × 7 × 6 ± 0.5) mm |
| Drive Speed | 200 rpm ± 5% |
| Load | 20 kg ± 1% |
| Friction Ring | φ40 × 10 mm, HRC 40–45. chamfer 0.5 × 45°, concentricity deviation < 0.01 mm |
| Friction Torque | 0–4 N·m ± 2% |
| Equipment Weight | 52 kg |
| Packed Weight | 82 kg |
| Equipment Dimensions (L × W × H) | 500 × 460 × 320 mm |
| Packed Dimensions (L × W × H) | 650 × 600 × 550 mm |
