Safety Footwear Compression Puncture Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
TheSafety Footwear Compression Puncture Testeris designed to evaluate the compression resistance of safety footwear toe caps and the puncture resistance of midsole steel plates. The instrument simulates real working conditions to ensure that safety shoes provide sufficient protection against crushing and sharp object penetration, reducing the risk of injury in industrial environments. It is widely used for product development, quality control, and certification testing.
Application
This tester is suitable for:
(1)Safety Footwear Manufacturing:Verifies toe cap compression strength and midsole puncture resistance.
(2)Quality Control Laboratories:Ensures compliance with international safety standards.
(3)Third-Party Testing Institutions:Provides reliable data for certification and inspection.
(4)Industrial Safety Evaluation:Assesses protective performance of footwear used in construction, mining, and manufacturing industries.
Standards
(1) BS EN 344 – Safety footwear testing methods (ISO standards equivalent)
(2) ANSI Z41 – Personal protection protective footwear standard
(3) ISO 20344 – Personal protective equipment – Test methods for footwear
(4) GB – China national standards for safety footwear
(5) JIS – Japanese industrial standards for footwear testing
Parameters
| Parameter | Specification |
|---|---|
| Compression Force (EN) | 15 ± 0.1 kN |
| Compression Force (ANSI) | 1000 ± 50 – 10000 ± 50 lbs |
| Maximum Load | 500 kg |
| Load Cell | High-precision pressure load cell |
| Compression Speed | Stepless adjustable |
| Unit Switching | kg / N / lb |
| Resolution | 1/10000 |
| Safety Features | Upper limit protection, peak retention, automatic shutdown |
| Dimensions (L×W×H) | 712 × 330 × 828 mm |
| Weight | 115 kg |
