Limiting Oxygen Index Tester
Get a quote：
Whats/App: +86 181 0160 0864
Web: gellowen.co.uk
The Limiting Oxygen Index Tester measures the minimum oxygen concentration needed to sustain combustion of solid materials like textiles and plastics. Samples are fixed vertically in a transparent cylinder with an oxygen-nitrogen mixture, ignited at the top, and observed for combustion characteristics. By comparing burn time or length against limits, the ultimate oxygen index is determined, offering an efficient, user-friendly method for material research and quality control.
Application
This instrument measures the minimum oxygen volume percentage concentration at just required for maintaining combustion of the polymer.it is suitable for a wide range of materials by changing the sample fixture used in a variety of mechanical properties of the sample.lt can be used for the determination of burning performance of plastics, rubber, fiber, foam, film, textile and wood.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
Standards
GBT 2406.1 Plastics Test of burning behaviour by oxygen index-Part 1: guideline;
GBT 2406.2 Plastics Test of burning behaviour by oxygen index -Part 2: Indoor-temperature test;
GBT 5454 Textiles Performance test of burning by oxygen index;
GBT 10707 Rubber Performance test of burning behaviour;
ISO 4589-2 Plastics Test of burning behaviour by oxygen index -Part 2: Indoor-temperature test;
ASTM -- D2863 Standard Test Method for Measuring the Minimum Oxygen Concentration of material combustion which is similar to plastics material (Oxygen Index);
IS0 4589-3 (Please inquire separately for the apparatus for the
ISO 4589-2 " Plastics -- Determination of burning behaviour by oxygen index -- Part 2: Ambient-temperature test”
NES 714. EN 45545-2.JIS 7201. BS 2782. etc.,
Features
Imported sensors
Imported Paramagnetic oxygen concentration sensor with high precision and stable performance.Real-time detection of oxygen concentration with PLC precise control so that can adjust the oxygen concentration through the airflow.
Flexible fixture design
The fixture is made of refractory and stainless material, which can resist high temperature and rust.It can hold various samples.By replacing the sample holder, the sample requirements of different characteristics can be fulfilled.
Linited Oxygmn Indes Testet
Intelligent touch operation 7-inch color screen, intelligent touch, multi-touch operating system, convenient operation, multi-language display, switching between
Chinese and English.Simplified operation interface, easy to operate
Quick change structural design
The test tube of this instrument which is made of high temperature resistant transparent glass combing with the base adopts quick change design to clearly observe the combustion situation in the test. Moreover, it is easy to clean after the test. The stainless steel base can avoid the influence of various corrosion on the test data, and its service life is long.
Parameters
|
Operating mode: Full color touch screen control |
Control range:0~100%, ±0.2% |
|
Language:Chinese-English interface |
Inlet air pressure:≤1MPa |
|
Burner:Inner Radius79mm;height500mm |
test air pressure:0.15-0.2MPa |
|
Glass beads: 4mm,height 80-100mm |
Gas flow rate: 12.01L/min |
|
Igniter inner diameter:2mm |
Dimension:700 mmx750mmx460 mm |
|
Igniter length:400mm |
Weight:45kg |
|
Air inlet: 7mm |
Power supply:220V 50Hz |
