Multi-Function Friction Wear Tester ASTM G99
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Multi-Purpose Friction and Wear Tester is a laboratory testing system designed to evaluate friction behavior and wear performance of engineering materials under controlled contact, load, speed, and temperature conditions. You can use this instrument to conduct standardized and comparative tribological testing by simulating rolling, sliding, and mixed lubrication conditions commonly encountered in industrial applications.
Standards
GB/T 3960 — Method for Friction Testing of Metals
GB/T 3961 — Method for Wear Performance Testing of Materials
ASTM G77 — Block-on-Ring Wear Testing Method
ASTM G99 — Ball-on-Disk Wear Testing Method
ISO 7148-2 — Plain Bearings and Lubrication Friction Testing
DIN 50324 — Standard Methods for Friction and Wear Testing
Parameters
| Item | Specification |
|---|---|
| Contact geometry | Crossed cylinder / Ball-on-cylinder / Block-on-ring / Double roller |
| Center distance | 60 mm |
| Roller diameter | 60 mm |
| Sliding specimen | 12.7 mm ball, roller, or block |
| Speed range | 30 – 850 rpm |
| Maximum sliding speed | 4.7 m/s |
| Slip ratio settings | 0.00%, 3.33%, 5.00%, 10.00%, 15.00%, 20.00% |
| Maximum friction force | 130 N |
| Friction force measurement | Strain gauge sensor |
| Load range | 50 – 750 N |
| Load actuator | Pneumatic cylinder |
| Load control | Precision pressure regulator |
| Load measurement | Pressure sensor |
| Test chamber temperature | Ambient to 150 °C |
| Heating power | 150 W |
| Temperature sensor | Type K thermocouple |
| Motor | Brushless DC servo motor, 200 W |
| Control mode | Speed, temperature, and test duration automatic; load manual |
| Measured parameters | Speed, load, friction force, temperature, revolutions, time, sliding distance, friction coefficient |
| Software interface | USB communication module |
| Power supply | 220/240 V, single phase, 50 Hz, 1.2 kW or 110/120 V, single phase, 60 Hz, 1.2 kW |
Features
Multiple contact geometries allow you to perform a wide range of tribological tests on one platform
High-precision friction force measurement ensures reliable and repeatable results
Fixed slip ratio options enable controlled simulation of rolling–sliding contact conditions
Pneumatic loading provides stable force application with fast response
Sealed and heated test chamber supports both lubricated and dry friction testing
Quick specimen replacement supports metals, polymers, elastomers, and ceramics
Integrated data acquisition enables continuous monitoring and automated testing workflows
Accessories
(1) Roller specimens with selectable material options
(2) Ball specimens with standard diameter
(3) Block specimens for block-on-ring testing
(4) Block-on-ring fixture compatible with ASTM requirements
(5) Pneumatic loading assembly with pressure regulator
(6) Heated test chamber with temperature sensor
(7) Data acquisition and control software
