Scratch Test Machine | ISO 1518 Standard Tester
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
The system supports testing in accordance with the following international standards:
ASTM C1624 – Standard test method for adhesion strength and scratch resistance of ceramic and hard coatings
ISO 20502 – Coating materials – Scratch test method
DIN EN 1071-3 – Plastics and coatings – Determination of scratch and wear resistance, Part 3: Test method
Parameters
| Item | Specification |
|---|---|
| Overall dimensions | 630 × 650 × 610 mm |
| System weight | 100 kg |
| Applicable coating thickness | ≥ 1 μm |
Features
Provides multiple loading modes, including progressive loading and constant loading.
Supports three analysis methods:
Optical microscopy
Friction force monitoring
Acoustic emission detection
Equipped with an intuitive user interface, allowing quick familiarization and operation.
Utilizes a motor-driven XY platform and Z-axis lift, enabling fast and stable measurement.
Capable of generating test reports easily, improving documentation efficiency.
Accessories
(Standard accessories supplied with the system include, but are not limited to:)
Motorized XY platform
Z-axis lifting mechanism
Scratch indenter system
Data acquisition and analysis software
Optical observation module
(Accessories are listed based on the functions described in your provided information.)
