Artificial turf wear tester

Get a quote：

Whats/App: +86 181 0160 0864

Web: gellowen.co.uk

An artificial turf wear tester is a device specifically designed to evaluate the wear resistance of artificial turf. It tests the wear performance of artificial turf by simulating friction conditions encountered during actual use.

Applications

1. Assessing Wear Resistance

The artificial turf wear tester simulates real-world friction conditions to test the wear resistance of artificial turf. This helps understand the turf's wear performance under different conditions, providing data support for its performance in practical applications.

2. Quality Control and Inspection

During the production process, this equipment can be used to test whether the artificial turf meets the predetermined wear resistance requirements. This helps ensure the consistency and stability of product quality, reducing return and repair costs caused by quality issues.

3. Product Development and Optimization

Testing with the artificial turf wear tester provides data support for product development and optimization. For example, when developing new materials or processes, this equipment can be used to evaluate the impact of different solutions on wear resistance, thus selecting the best solution.

4. Standard Setting and Verification

This equipment can also be used to develop and verify wear resistance standards for artificial turf. Through the accumulation and analysis of a large amount of test data, more scientific and reasonable wear resistance standards can be established, providing a basis for quality control and inspection in the industry.

Standards

(1)FIFA Quality Programme: Exceeds 2015/2016 handbook requirements for artificial turf abrasion resistance testing

(2)EN 15330-1: European standard for shock absorption and deformation recovery in synthetic sports surfaces

Features

(1)Abrasion System:

Rubber-Coated Discs: 200mm diameter with 60 Shore A hardness.

Particle Rollers: Interchangeable grit inserts (40/60/80 mesh).

(2)Control Panel:

10” HMI touchscreen with pre-loaded FIFA test protocols.

USB/Ethernet ports for PC connectivity and remote diagnostics.

(3)Safety Systems:

Emergency stop with E-Stop loop monitoring.

Overload protection at 110% of rated capacity.

Software Suite:

(4)TurfDur Pro™: Auto-calculates abrasion resistance (FIFA stars) and fiber loss.

Cloud Sport: Remote monitoring for global R&D teams.

(5)Illumination:

Adjustable LED array (3.000–6.500K color temperature).

Anti-glare diffusers for operator comfort.

Technical Parameters

Specification	Details
Test Area	12m² (1m × 12m)
Speed Range	0.1–1.0 m/s (adjustable in 0.01 m/s steps)
Cycle Capacity	1–10.000 cycles (pre-settable intervals)
Power Supply	380V/32A/50Hz (3-phase)
Dimensions (W×D×H)	6.500mm × 2.000mm × 1.800mm (folded)
Expanded Footprint	8.000mm × 3.000mm × 2.200mm (operational)
Weight	1.500 kg (net)
