Automotive Wire Insulation Manual Bend Test System Factory Direct
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Parameters
| Parameter | Specification |
|---|---|
| Clamp Type | Manual |
| Clamp Spacing | 0–500 mm adjustable |
| Total Cycles | 0–999.999 cycles (manual setting) |
| Test Speed | 20 cycles/min |
| Off-Center Distance | 50. 75. 100. 150 mm |
| Sample Parallel Section Diameters | φ4 mm, φ6 mm, φ8 mm, φ10 mm, φ12 mm, φ15 mm, φ18 mm, φ20 mm |
Features
(1) Manual operation with adjustable clamp spacing.
(2) Supports a wide range of wire diameters (4–20 mm).
(3) Bidirectional rotation ensures uniform stress application.
(4) Cycle count can be set manually up to 999.999 cycles.
(5) Simple, reliable mechanical design for consistent test results.
Accessories
(1) Set of clamps for various wire diameters.
(2) Calibration manual.
(3) Instruction and operation manual.
(4) Adjustable off-center distance accessories.
(5) Optional data recording sheet.
Test Procedures
(1) Insert the wire sample through the specified circular hole of the clamp.
(2) Secure the wire in the fixture at the preset spacing.
(3) Set the total number of bending cycles.
(4) Start the test; the wheel rotates the wire sample in the selected direction.
(5) Upon completion or wire failure, stop the test.
(6) Inspect the wire for cracking, surface damage, or strand breakage.
(7) Record the test results for quality assessment.
