Washing Fastness testing machine
G228B washing fastness tester is used for washing, dry-clean color fastness testing. Electric touch switch, LCD menu display, without mechanical contact, safe and reliable. Specimens shelves driven stable and reliable, change washing cup is convenient. With 500ml and 1200ml two kinds of washing cups, meet different testing standards. Heating tube has no noise, long life, temperature control is accurate.
Application
Various textiles color fastness to washing, dry-cleaning and poaching. Detergent efficiency and color fastness to washing, dry cleaning test. Maximum temperature reach 98 ℃ , can also assess the dyes washing color fastness.
Standard
·ISO 105 C01 C02 C03 C04 C05 C06 C08 D01 color fastness for textile
·BS 1006 C01 C02 C03 C04 C05 color fastness for fabrics and leather
·NEXT TM235 M&S C4 C5 C10A P3B
·GB/T 3921 5711 Textile color fastness to washing.
Technical Parameters
Washing color fastness tester, measuring vessel position: 24+12
Rotary speed:40 ± 2 rpm
Device control method:Digital, can set the program freely.
Measuring cup size:1200 ± 10ml 和550 ± 10ml
Chamber has the rotary function.
Features
Auto alarm when testing over.
Structure is made of 316 stainless steel
With specimen cup auto switch function
Max temperature can reach 98℃
Temperature accuracy:±0.3℃
Temperature control: Microprocessor control, display temperature and time.
Overflow alarm function
Dry heating alarm function protect the instrument not damage
The measuring cover with double layer insulation function, reduce the heat loss to minimum. Reduce heat frequency, protect the heat tube working life.
Test panel uses pneumatic rod, save labor cost, and also protect the operator.
Hide pressure discharge function, when the chamber pressure is higher, cooled water drop discharge from snake type pipe
With forklift position, can move by forklift.
Accessory
·550 ml stainless steel cup 24 pcs ·1200 ml stainless steel cup 12pcs ·Steel bead for washing 2000 pcs ·550 ml SS cup washing seal 20pcs/pack ·1200ml SS cup washing seal 20pcs/pack ·550ml SS cup dry-clean seal 20 pcs/pack |
·1200ml SS cup dry clean seal 20 pcs/pack ·Stainless steel dry clean slice 50pcs ·DW multi fiber lining fabric 10m/pack ·AATCC multi fiber lining fabric 1m/pack ·Standard ECE detergent B(WOB) 2 bucket ·AATCC standard detergent (WOB) 2 bucket |
