Medical injection needle tip puncture force tester

Product characteristics

  Using 7-inch K600+ core/dot-matrix 65 color 800*480 resolution touch screen display,

PLC control system dynamically displays the loading force value; Operation interface

Optional: Chinese/English/English switch; Digital closed loop control, AD acquisition speed

is 500KHz, internal code is 500000; High precision clock chip, power off storage; Overload

alarm stop protection; Touch operation: nominal specifications, tubes, test times, pressure,

up, down, time, calibration. Real-time display of piercing force and peak force data, can display

the maximum piercing force and F five peaks, and printed by the on-board printer test results.

enforce standards

  GB15811-2016 "Disposable Sterile Injection Needle"

Technical parameter

  1. Nominal specification :0.18——3.4mm;

  2. Test range :0——5.00N, error is not more than 0.5%; Resolution :0.001N

  3. Moving speed :100mm/min; The error is not more than 5%;

  4. Printing method: Each time can print 8, 13 or 20 times of test data and average puncture

force and difference.

  5. Shipping list: 1 set of host, 1 certificate, 1 fixture, 1 operation manual, 1 roll of printing

paper, supporting weights.

  6. Power supply :AC90V-240V/50Hz

  7. Data storage: on-board needle printer/U disk can be imported to computer storage

  8. Net weight :10kg Dimensions :300x240x240(mm)

  9. Services: Non-standard instruments can be customized

  10. The instrument is free to upgrade service and maintain for life according to national sta
