Carpet tuft length measuring instrument
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
- BS 4223:1989 (British Standard): Specifies methods for determining the pile length of cut-pile carpets, ensuring consistency in quality control and product certification.
Product Advantages
- Consistent Measurement: V-groove acrylic body ensures uniform alignment of tufts for repeatable results.
- User-Friendly Design: Intuitive workflow requires no special training—measure 20+ tufts in minutes.
- Durable Construction: Anodized aluminum block and scratch-resistant glass rod withstand industrial use.
- Portable Precision: Compact design (250 × 150 × 50 mm) for on-site quality inspections.
- Global Compliance: BS 4223 certification simplifies export compliance for 150+ countries.
- Low Maintenance: Non-corrosive materials and modular components reduce downtime.
Product Features
- Precision V-Groove Fixture: Self-aligning acrylic body holds tufts at 45° for accurate straightening.
- Tempered Glass Rod: Uniform pressure application prevents tuft distortion during measurement.
- Etched Metal Ruler: Laser-engraved 0–50 mm scale with 0.1 mm resolution (±0.05 mm accuracy).
- Modular Design: Interchangeable components adapt to loop pile/cut pile configurations.
- Non-Slip Base: Rubberized feet ensure stability on laboratory benches or production floors.
- Calibration Port: NIST-traceable verification slot for annual compliance checks.
Technical Parameters
| Parameter | Specification |
|---|
| Measurement Range |
0–50 mm (0.1 mm increments) |
| Accuracy |
±0.05 mm (BS 4223 compliant) |
| Tuft Capacity |
20+ tufts per test cycle |
| Material |
Anodized aluminum/acrylic/tempered glass |
| Dimensions (W×D×H) |
250 × 150 × 50 mm |
| Weight |
1.2 kg (net) |
| Operating Temperature |
10°C–40°C |
| Humidity Tolerance |
10–90% RH (non-condensing) |
Accessories
- Pile Alignment Kit:
- V-groove acrylic body with 45° alignment guides
- Tempered glass pressure rod (150 mm length)
- Precision Ruler:
- Etched stainless steel scale (0–50 mm, 0.1 mm divisions)
- NIST-traceable calibration certificate
- Tuft Extraction Tool:
- Stainless steel tweezers with anti-static coating
- Carrying Case:
- Foam-lined ABS enclosure with custom cutouts
- User Manual:
- Multilingual guide (English/Spanish/Arabic)
- Cleaning Kit:
- Microfiber cloth + isopropyl alcohol wipes
