Precision Fiber Slicer
Whats/App: +86 156 1874 6768
Web: standard-groups.com
G214Precision Fiber Slicer is used to make the accurate fiber cross-sectional specimens for further inspection or research under the microscope. Insert a bundle of degreased fibers into the fine holes in the upper part of the micro-tome. The insert media is suitable for fiber bundles and can be dried. The fiber bundle is placed on the ejectorand the micrometer is used to determine the desired fiber sample thickness, and the slices can be cut with blade.
Application
G214 Precision Fiber Slicer is used to make accurate fiber cross-section specimens for further inspection or research under the microscope.
It is applicable to the performance verification of new products, quality control of the production department, and the of material properties for the third-party testing organization, the product performance verification laboratory, and the quality and technical supervisiondepartment, etc.
(1) Preparation of fiber cross-sections for microscopic analysis.
(2) Diameter measurement of wool, animal fibers, synthetic fibers, and other textile filaments.
(3) Quality control in textile production lines to verify fiber uniformity and performance.
(4) R&D laboratories developing new fiber types or evaluating fiber modifications.
(5) Third-party testing laboratories and certification agencies performing material property verification.
(6) Educational demonstrations in textile and materials science courses.
(7) Comparative analysis of fiber batches for process optimization.
Standards
ASTM D2130 Test method for determining the diameter of wool and other animal fibers by microprojection;
BS 2043 Method for measuring fineness of hair fiber by projection microscope;
DIN 53811 Inspection of textiles; Measurement of fiber diameter from longitudinal projection of microprojection
ISO 137 Determination of the diameter of wool fibers - projection microscopy;
IWSTM 24 Method for measuring the diameter of solvent extracts of wool and other animal hair
IWTO 8-6
Major Features
Precision cutting available
The slicer is equipped with precision indexing plate, which can cut a section of 10 microns and has an accurate cutting size for testing and analysis.
Quick loading fixture
Sliding plate fixed seat of the slicer is fastened with quick-twist type nuts, which can be quickly installed, loading convenient, reliable and efficient.
Flexible and compact design
The flexible and compact design makes this tester easy to assemble, which can be installed and tested from the lab to the production line at anytime and anywhere
Technical Parameters
|
Trial mode: manual |
Metal needle width: 1.5mm |
|
Slide width:30 |
Metal needle thickness:0.8mm |
|
Slide length:60mm |
Weight:3kg |
|
Slide thickness:3mm |
Power supply:no |
|
Slot width:1.5mm |
Dimension:150mm*100mm*150mm |
Operation Instructions:
Accessories
(1) Precision blades for slicing fibers.
(2) Quick-twist nuts for sliding plate attachment.
(3) Ejector plate for fiber specimen removal.
(4) Micrometer adjustment wheel for precise cutting thickness.
(5) User manual and product qualification certificate.
Maintenance Information
(1) Clean the blade and cutting area regularly to avoid residue build-up.
(2) Check and tighten micrometer and sliding components periodically.
(3) Store in a dry environment to prevent corrosion of metal parts.
(4) Handle blades carefully; replace if damaged or dull.
(5) Inspect quick-twist nuts and ejector plate for smooth operation.
