Standard light source sample table
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
ISO 3664:2009: Meets international standards for graphic arts and photography view conditions.
DIN 6173-2: European norm for illuminant D50 and D65 spectral requirements.
ANSI CGATS.6: North American color management protocols for print production.
Product Advantages
1. Consistent Color Verification
Multi-Source Illumination: D65 (artificial daylight), D50 (warm daylight), TL84 (retail), CWF (cool white) modes eliminate metamerism risks.
ISO-Certified Lighting: Simulates global retail/commercial lighting conditions.
2. 24/7 Color Accuracy
Critical for Night Shifts: Maintains D65 consistency during off-hour production checks.
30-Minute Warm-Up: Ensures stable CRI ≥95 before critical evaluations.
3. User-Centric Design
Intuitive Controls: Separate switches for each illuminant with auto-countdown timer.
Spacious Work Surface: 1.200mm × 600mm (47” × 24”) for side-by-side sample comparison.
4. Low Maintenance
2.000-Hour Lamp Life: High-efficiency T8 tubes with replaceable European components.
Tool-Free Lamp Replacement: Quick-release access panel for easy servicing.
5. Industrial Durability
Steel Housing: Powder-coated finish resists scratches and chemical spills.
Anti-Glare Diffuser: Eliminates specular reflections on glossy samples.
Product Features
Lighting System:
5 Illuminants: D65 (6.500K), D50 (5.000K), TL84 (4.000K), CWF (4.150K), UV (365nm).
Flicker-Free Output: Electronic ballasts ensure stable CRI ≥95.
Control Panel:
Illuminated switches with status LEDs.
Digital hour counter tracks lamp usage.
Safety Systems:
Overcurrent protection (2A fuse).
Residual current device (RCD) for operator safety.
Ergonomics:
Adjustable height stand (700–1.100mm) for standing/seated use.
Removable center divider for large-format samples.
Maintenance:
Lamps accessible via magnetic front panel.
Washable diffuser panel (IP54-rated).
Accessories & Options
Lamp Kits:
D50/D65/TL84/CWF replacement tubes (18W–58W).
UV-A lamps for fluorescent agent detection.
Calibration Services:
Annual ISO 3664 certification with spectral report.
On-site lamp replacement training.
Safety Upgrades:
Floor-standing base with locking casters.
Anti-fatigue mat for extended use.
Consumables:
10 × Replacement diffuser sheets.
1L Glass cleaner for diffuser maintenance.
Warranty:
12-month manufacturer’s warranty (extendable to 36 months).
Lifetime technical support via global hotline.
Technical Parameters
| Specification | Details |
|---|---|
| Work Surface | 1.200mm × 600mm (47” × 24”) |
| Illuminants | D65/D50/TL84/CWF/UV (selectable) |
| Lamp Type | T8 fluorescent (18W/36W/58W) |
| Color Rendering Index | CRI ≥95 (D65/D50), CRI ≥85 (TL84/CWF) |
| Power Supply | 100–240V/50–60Hz (auto-switching) |
| Dimensions (W×D×H) | 1.250mm × 650mm × 1.100mm |
| Weight | 45 kg (net) |
