Dust Chamber MIL STD 810
Features and Benefits
Themil std 810 test chamberis made ofSUS304. which can withstand the impact of sand and dustunder high wind speedfor a long time and wear, ensuring the service life of the equipment.Double rubbersealing, prevent sand and dust leakage.
Accurate test parameter control, the workroom is equipped with temperature probe, wind speed probe, concentration probewhich ensure accurate data and timely return to the controller.
Water circulation cooling system,The sand flying in the high wind speed in the workroom and pipe, and the inner wall of the pipe friction to produce high heat. Three water tanks are arranged outside the pipe for water circulation, and a circle of water surrounds the outer wall of the wind speed pipe to cool it.
Dust circulation:the bottom of the test chamber is a funnel-shaped structure, and the dust falling to the bottom is collected and filtered by the collection portthroughmesh sieve, and then inhaled and raised by the fan again to realize the repeated recycling of sand and dust.
Specifications
|
Model |
STD DIM-1000 |
|
Internal Dimension |
1000*1000*1000mm D*W*H |
|
Overall Dimension |
3000*6100*2200mm D*W*H |
|
Interior Volume |
1000L |
|
Blowing Dust |
|
|
Air velocity |
1.5 -8.9m/s |
|
Concentration of dust |
10.7±7g/ m³ |
|
Dust particles |
<150μm |
|
Blowing sand |
|
|
Air velocity |
18.0 -29.0m/s |
|
Concentration of sand |
0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³ |
|
Sand particles |
149μm - 600μm, 600μm - 850μm |
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|
Testing Platform Diameter |
600mm |
|
Door Lock |
Electromagnetic lock |
|
Testing Platform Speed |
1-7 r.p.m |
|
Dust Detector |
Integrated dust detector |
|
Exterior Material |
A3 Steel Plate with protective coating |
|
Interior Material |
SUS304 stainless steel |
|
Standard |
MIL-STD- 810 |
