PV-Panels Testing Devices
Features and Benefits
1. The capacity and performance of the workroom can be adjusted according to the size of the photovoltaic panel and your needs.
2. The control of temperature and humidity is very accurate, and the temperature and humidity deviation of±2.5%RH and±2.0℃can be reached in the workroom with large space.
3. The sample holder can be customized, including the angle of the photovoltaic panel, the number of tests, etc.
4.PV-panelstestingdevicescan test in accordance with relevant international standards and regulations to ensure that photovoltaic panel products meet market access requirements.
Specifications
Model |
STD PV-04 |
||
InternalDimension (mm) |
1300*700*1350 |
||
OverallDimension (mm) |
1900*1100*1750 |
||
Interior Volume |
1220L |
||
Parameter |
TemperatureRange |
-60℃～+100℃ |
|
TemperatureFluctuation |
± 0.5℃ |
||
TemperatureDeviation |
± 2.0℃ |
||
Humidity Range |
20% ~ 98% RH |
||
Humidity Deviation |
± 2.5% RH |
||
Temperature ChangeRate |
1~ 3.4℃/Min |
||
Panel Size |
1M*2M |
||
Panel Capacity |
4 / 6 / 8 / 10 / 12 Pieces |
||
Controller |
Programmable colorLCDtouch screen controller |
||
|
Ethernet connection, PC Link, USB |
|||
Humidity |
Water supply system |
Automatic water supply |
|
|
Water supply system |
Water purification system |
||
|
Humidifier |
External isolation, stainless steel surface evaporation humidifier |
||
|
Dehumidification |
Evaporator |
||
Sensor |
TemperatureSensor |
PTR Platinum Resistance PT100Ω/MV A-class,accuracy0.001℃ |
|
|
HumiditySensor |
Dry and wet bulb sensor |
||
Build-inWaterTank(mm) |
270*300*450 |
||
View Window Size(mm) |
330*370 |
||
Air Circulation |
Centrifugal windfan |
||
SafetyDevice |
HumidifierDry-combustionProtection;Over-temperatureProtection; Over-currentProtection; RefrigerantHigh-pressureProtection;WaterShortageProtection; Earth leakageProtection |
||
