Constant Temperature and Humidity Test Chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Features and Benefits
1. Precise Control
Advanced system with ±0.1°C temperature accuracy and ±2.5%RH humidity accuracy. Nichrome heater and stainless steel humidifier ensure stable performance.
2. Uniform Conditions
Top-mounted fan provides effective air circulation for consistent temperature and humidity throughout the chamber.
3. Energy Efficient
Uses polyurethane foam insulation to reduce energy consumption and operating costs, supporting eco-friendly operation.
4. Wide Application
Suitable for electronics, automotive, chemical, biomedical, and other industries to meet diverse testing requirements.
Specifications
|
Model |
STD TH-100 |
STD TH-500 |
STD TH-800 |
STD TH-1000 |
|
Internal Dimension (mm) |
400*500*500 |
700*800*900 |
800*1000*1000 |
1000*1000*1000 |
|
Overall Dimension (mm) |
900*1050*1620 |
1200*1340*2020 |
1300*1540*2120 |
1500*1540*2140 |
|
Interior Volume |
100L |
500L |
800L |
1000L |
|
Heat load |
1000W |
|||
|
Temperature Range |
A : -20℃～+150 ℃ B : -40℃～+150 ℃ C: -70℃～+150 ℃ |
|||
|
Temperature Fluctuation |
± 0.5 ℃ |
|||
|
Temperature Deviation |
± 2.0 ℃ |
|||
|
Humidity Range |
20% ~ 98% RH |
|||
|
Humidity Deviation |
± 2.5% RH |
|||
|
Cooling Rate |
1 ℃ / min |
|||
|
Heating Rate |
3 ℃ / min |
|||
|
Cooling system |
Mechanical compression refrigeration system |
|||
|
Controller |
Programmable color LCD touch screen controller, Ethernet connection |
|||
|
Water supply system |
Automatic water supply, Water purification system |
|||
|
Safety Device |
Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection; Earth leakage protection |
|||
|
Exterior Material |
Steel Plate with protective coating |
|||
|
Interior Material |
SUS304 stainless steel |
|||
