Carpet Dimensional Stability Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
- ASTM D5417(Standard Test Method for Assessing Carpet Dimensional Stability)
- ISO 2551(Textile Floor Coverings - Determination of Dimensional Changes After Exposure to Heat and Humidity)
- BS 4682
Product Advantages
- Unmatched Precision
- High-resolution laser sensors (±0.01mm accuracy) capture even minute dimensional changes, critical for delicate wool, synthetic, and blended carpets.
- Adaptive Testing Environment
- Programmable climate control (temperature: 10–60°C, humidity: 20–95% RH) simulates extreme real-world conditions, from arid deserts to humid tropics.
- User-Centric Design
- 7-inch touchscreen interface with multilingual support (English, Spanish, Arabic, Japanese) and real-time data visualization for intuitive operation.
- Rugged Durability
- Stainless steel test chamber and corrosion-resistant components ensure long-term reliability in industrial settings.
- Cost-Efficient Operation
- Modular design allows easy replacement of consumables (e.g., humidity sensors, clamps) and minimizes maintenance costs.
Product Features
- Multi-Mode Testing:
- Supportsheat aging,humidity exposure, andmechanical stresstests to replicate washing, steam cleaning, and heavy foot traffic.
- Automatic cycle counter with pause/resume functionality for uninterrupted workflows.
- Safety & Compliance:
- Over-temperature protection, emergency stop button, and CE/UL certification for safe laboratory use.
- Data Management:
- Onboard memory stores 10,000+ test results, exportable via USB/Bluetooth in CSV/PDF formats. Compatible with LIMS (Laboratory Information Management Systems).
- Universal Sample Compatibility:
- Adjustable clamp system accommodates carpets up to 1m x 1m in size, including shag, loop pile, and cut-pile designs.
Technical Parameters
| Parameter | Specification |
|---|---|
| Dimensional Measurement Range | ±50mm (X/Y axis) |
| Temperature Range | 10–60°C (±0.5°C accuracy) |
| Humidity Range | 20–95% RH (±2% RH accuracy) |
| Test Cycle Duration | 1–999 hours (adjustable) |
| Sample Size | Up to 1m x 1m |
| Power Supply | 100–240V AC, 50/60Hz, 300W |
| Dimensions (L×W×H) | 1.2×1.2×2.0 m |
| Weight | 150 kg |
| Operating Environment | 15–35°C, ≤85% RH (non-condensing) |
