Carpet Abrasion Resistance Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
- ASTM D4157(Standard Test Method for Abrasion Resistance of Textile Fabrics (Oscillatory Cylinder Method))
- ISO 12947-2(Textiles - Determination of Abrasion Resistance - Part 2: Martindale Method)
- EN 14465(Resistance to Abrasion for Carpets)
Product Advantages
- Unmatched Precision
- High-resolution load sensor (±0.1N accuracy) and programmable test cycles deliver repeatable results for wool, synthetic, and blended carpets.
- Adaptive Testing Modes
- Supportsrotary(ASTM D4157) andplanar(ISO 12947) abrasion methods to replicate light residential use to heavy commercial traffic.
- User-Centric Design
- 7-inch touchscreen control panel with multilingual support (English, German, Spanish, Chinese) and real-time data visualization.
- Industrial-Grade Durability
- Stainless steel test chamber, corrosion-resistant components, and anti-vibration feet ensure long-term reliability in busy labs.
- Cost-Efficient Maintenance
- Modular design allows easy replacement of abrasive heads and clamps, minimizing downtime and operational costs.
Product Features
- Customizable Testing Parameters:
- Adjustable test speed (10–120 rpm) and load pressure (1–50 N) to simulate everything from bare feet to heavy furniture movement.
- Automatic cycle counter with pause/resume function for uninterrupted workflows.
- Safety & Compliance:
- Emergency stop button, over-temperature protection, and CE/UL certification for safe operation.
- Data Management:
- Onboard memory stores 10,000+ test results, exportable via USB/Bluetooth in CSV/PDF formats. Compatible with LIMS (Laboratory Information Management Systems).
- Universal Sample Compatibility:
- Adjustable clamps accommodate carpets up to 500mm in diameter (rotary mode) or 300×300mm (planar mode).
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Speed Range | 10–120 rpm (±1 rpm accuracy) |
| Load Capacity | 1–50 N (adjustable in 0.1N increments) |
| Sample Size (Rotary) | Up to 500mm diameter |
| Sample Size (Planar) | 300×300mm |
| Abrasive Head Diameter | 150mm (standard Martindale H-18) |
| Power Supply | 100–240V AC, 50/60Hz, 300W |
| Dimensions (L×W×H) | 600×500×800 mm |
| Weight | 90 kg |
| Operating Environment | 15–35°C, ≤85% RH (non-condensing) |
Accessories Included
- Abrasive Heads(2 pcs): Standard H-18 (planar) and CS-17 (rotary) for versatile testing.
- Sample Clamps(3 sets): For loop-pile, shag, and flat-weave carpets.
- Dust Cover: Transparent acrylic shield for operator safety.
- Calibration Kit: Weight set and gauge for annual equipment verification.
- User Manual & Software: Digital guide (multilingual) + PC software for advanced data analytics and ISO-compliant report generation.
Ideal For:
- Carpet manufacturers (residential, commercial, hospitality)
- Textile testing laboratories
- Flooring retailers requiring durability certifications
- Architectural firms specifying high-traffic carpets
