Full Notch Creep Tester / Full Notch Creep Test FNCT
Standard
ISO 16770: Exclusively designed for full-notch creep testing (FNCT) of thermoplastics under sustained stress.
ASTM D2990: Configurable for tensile, compressive, and flexural creep testing of polymers and composites.
ISO899
ISO3501
Product Advantages
1. Uncompromising Precision
Independent 6-Zone Control: Each station operates with ±1% force accuracy (0–2.000N) and ±0.1°C temperature stability.
Hybrid Loading System: Combines motorized force application with manual fine-tuning via touchscreen-guided weights.
2. Versatile Testing Environments
Dual Bath Compatibility: Switch between water (up to 95°C) and oil (up to 150°C) baths for high-temperature polymer analysis.
Expanded Force Capacity: Upgradeable to 4.000N max. load per station for heavy-duty applications.
3. Intelligent Monitoring
Auto-Level Sensing: Real-time solution height detection prevents test interruptions from evaporation or leaks.
Visual Alerts: Touchscreen displays color-coded status indicators for all stations.
4. Future-Ready Design
Modular Architecture: Add stations or upgrade controllers without replacing the entire system.
Multi-Language Interface: Operate in English, German, Chinese, or Spanish.
Technical Parameters
| Specification | Details |
|---|---|
| Stations | 6 fully independent test positions |
| Force Range (per station) | 0–2.000N (standard) / 0–4.000N (optional) |
| Temperature Control | Water: 40–95°C |
| Force Accuracy | ±1% FS (0.5% with calibration kit) |
| Power Supply | 220V/50Hz (110V/60Hz available) |
| Bath Capacity | 15L per station (90L total) |
| Dimensions (W×D×H) | 1.800mm × 750mm × 1.650mm |
| Weight | 380 kg (net) |
Send product request
