Solid Auto - ignition Point Tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Product Introduction
This tester determines the self - ignition characteristics of solid chemical products by placing the substances in a 20mm - side - length cubic wire mesh and increasing the temperature. It complies with standards such as GB/T 21756 - 2008 *Determination of the Relative Self - Ignition Temperature of Solid Substances in Chemical Products for Industrial Use* and NF T20 - 036.
Product Features
1. It adopts an embedded processor and the Windows CE operating system.
2. With an 8 - inch liquid - crystal touch screen, it can display the test status in real - time.
3. It supports two working modes, the "standard mode" and the "custom mode" (during the custom experiment, it can save the exothermic peak value in real - time, etc.), taking into account both the standardization and flexibility of the test.
4. It integrates high - temperature heat - insulation technology, temperature control, and precise detection technology.
5. It uses an electrically heated muffle furnace with natural air - circulation convection to ensure uniform heating of the samples.
6. The furnace cavity is made of heat - insulating vacuum ceramic fiber, which has a good heat - insulation effect.
7. The cubic wire mesh is hung at the bottom of the furnace cover, making it safe and convenient to place samples.
8. It realizes automatic heating control, temperature control, and combustion detection.
9. A cleaning rod is provided for cleaning the inner cavity's central through - hole.
10. A debris tray is provided to collect samples falling from the wire mesh and residual samples cleaned out by the rod.
11. A cooling bracket is provided to place the assembled furnace cover on it for cooling after the test.
12. It uses a thermocouple sensor to quickly and accurately respond to temperature changes.
13. It displays the time - temperature curve in real - time, and the original data can be viewed.
14. The test process is fully automated, requiring no manual intervention. It supports functions such as parameter setting, data storage, and report viewing.
Technical parameters
|
Working Environment |
(5～40)℃, <85%RH |
|
Test Objects |
Solid |
|
Temperature Control Range |
Room temperature～650℃ |
|
Standard Rise Rate |
0.5 ℃/min |
|
Customized Rise Rate |
(0.1～3.0)℃/min |
|
Temperature Measurement Range |
(0～800)℃ |
|
Temperature Measurement Resolution |
0.1 ℃ |
|
Temperature Measurement Accuracy |
±2.5 ℃ below 300 ℃ |
|
Heating Chamber Capacity |
±(0.75% of the reading) above 300 ℃ |
|
Timing Range |
2L |
|
Mesh Cage Size |
(0～96)h |
