Dental Implants Static Torsion Testing Machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
ISO 13498: Specifies static torsion testing protocols for dental implants, including torque application rates, failure criteria, and data reporting requirements.
ASTM F2077-17: Complementary compliance for mechanical performance evaluation of dental prosthetic components.
Product Advantages
Compact Ergonomics: Lightweight (35 kg) design with integrated touchscreen control panel for benchtop use.
Ultra-Precision Torque Control: 0.001 Nm resolution ensures compliance with ISO 13498's 0.01 Nm/s loading rate requirements.
Smart Fixturing System: Quick-change collets accommodate implant diameters (3.0–6.5 mm) and lengths (8–18 mm).
Automated SOP Protocols: Pre-loaded ISO 13498 test sequences with real-time torque-angle curve generation.
Biorelevant Simulation: 37±1°C environmental chamber with saline mist system for in vitro corrosion testing.
Global Compliance: CE-marked and FDA-ready documentation package for regulatory submissions.
Product Features
Servo-Electric Actuator: 50 Nm peak torque capacity with programmable rotation angles (0°–360°).
Dynamic Angle Measurement: 0.001° resolution encoder tracks micro-rotational movements.
Axial Force Simulation: Integrated 5 kN load cell for combined torsion/compression testing.
Thermal-Mechanical Chamber: 10L capacity with rapid temperature control (20°C–50°C).
High-Resolution Imaging: Built-in 2MP camera system for screw thread damage analysis.
Safety Suite: Emergency stop, overload clutches, and torque limiting protection.
Dental Implant Fixture Kit:
Self-centering collets (3.0–6.5 mm implant compatibility)
Thread engagement gauges (ISO 13498 compliant)
Thermal-Mechanical Chamber:
10L capacity with rapid heating (10°C/min)
Corrosion-resistant titanium interior
TorsionMaster Pro Software:
Automated torque-angle curve generation and failure analysis
21 CFR Part 11-compliant audit trail with blockchain timestamping
Remote monitoring via iOS/Android app
Operator Kit:
Calibrated torque wrench set (0.1–10 Nm)
Implant alignment jigs (ASTM F2077 compliant)
Calibration Bundle:
NIST-traceable torque calibration weights
Angular encoder verification tool
Safety Kit:
Torque limiting clutches
Acoustic enclosure with 25 dB noise reduction
Technical Parameters
| Parameter | Specification |
|---|---|
| Max. Torque | ±50 Nm (0.001 Nm resolution) |
| Rotation Range | 0°–360° (0.001° resolution) |
| Torque Application Rate | 0.01–0.10 Nm/s (ISO 13498 compliant) |
| Axial Force Capacity | ±5.000 N (5 N resolution) |
| Temperature Control | 20°C–50°C (PT1000 sensors) |
| Data Sampling Rate | 10 kHz (synchronized across 8 channels) |
| Power Requirements | 220V/110V ±10%, 50/60Hz, 800W |
| Dimensions (W×D×H) | 450 × 400 × 600 mm |
| Weight | 35 kg (net) / 45 kg (with chamber) |
| Noise Level |
