Bag lifting fatigue testing machine

Product Introduction:

This machine is suitable for up and down vibration fatigue test of plastic handbag, garbage vest bag, kraft paper bag, woven bag and other bags bearing a certain weight. After many fatigue tests, the strength of the bag can be determined. The bag lifting fatigue testing machine adopts the automatic test mode, placing the sample on the fixture, setting the lifting times and load weight, and automatically completing the experiment process and printing the results. This fatigue testing machine is widely used in quality inspection institutions and handbag manufacturers.

Standard:

ISO1167 ASTMD1598 ASTMD1599

Main parameters:

Amplitude: 30±2mm

Vibration frequency: 2——3HZ (130 times per minute)

Test space height: 500/1000mm

Load: 20Kg

Counting range: 99.999 times in a single cycle

Dimensions: 570mm*510mm*1520mm(length, width and height)

Weight: 60KG

Power supply: 220V 50Hz

Technical features:

Microcomputer control, large LCD display

Four-column structure, the fatigue test process is stable and reliable

PVC operating panel, humanized design

The number of bag lifting fatigue test can be set freely

Selection of excellent components, low noise, high life

The bag lifting fatigue machine comes with a printer, which can quickly print the experimental results

Bag weight can be set, the experimental results are clear

Test principle:

Fill three quarters of the bag with the particle mixture equivalent to twice the nominal mass of the contents, and then hang the lifting fatigue on the test machine, set the number of lifting bags, and observe whether there is damage at the lifting bag after the end.
