Rolling load tester
Standard
EN 1569: Determines rolling load resistance of synthetic sports surfaces (e.g., PU, PVC, rubber).
EN 14904: Tests performance of multi-sport indoor flooring under repetitive mechanical stress.
DIN 18032-2: German standard for impact attenuation and deformation recovery in athletic facilities.
Product Advantages
1. Universal Compatibility
Sample Thickness Flexibility: Tests materials from 2mm to 50mm (flooring, shock pads, seams).
Adjustable Load Range: 50N to 500N customizable for basketball, volleyball, and multi-purpose courts.
2. Automated Precision
Speed & Cycle Control: Programmable 1–10 cycles/minute with auto-pause at set intervals.
Self-Leveling Wheel: Maintains 0.5mm contact consistency across uneven seams.
3. Unobstructed Visualization
High-Clarity Enclosure: Polycarbonate dome with anti-fog coating for 360° process monitoring.
LED Task Lighting: Shadow-free illumination for residual indentation inspection.
4. User-Centric Design
Plug-and-Play Calibration: Pre-loaded EN 1569 protocols with touchscreen load adjustment.
Ergonomic Access: Sliding front panel for quick sample changes.
5. Regulatory Compliance
CE & TÜV Certified: Meets EU machinery directives for laboratory equipment.
Audit-Ready Reporting: 21 CFR Part 11 compliant data logging.
Product Features
Rolling System:
Hardened Steel Wheel: 75mm diameter with 20° chamfer for seam simulation.
Pneumatic Load Application: ±1N accuracy via digital pressure regulator.
Control Panel:
7” TFT touchscreen with real-time cycle counter and load visualization.
USB/Ethernet ports for PC connectivity and remote diagnostics.
Safety Systems:
Emergency stop with E-Stop loop monitoring.
Overload protection at 110% of rated capacity.
Software Suite:
FloorDur Pro™: Auto-calculates deformation recovery (DIN 18032-2) and residual indentation.
Cloud Sport: Remote monitoring for global R&D teams.
Illumination:
Adjustable LED array (3.000–6.500K color temperature).
Auto-dimming function for operator comfort.
Accessories & Options
Standard Kit:
EN 1569-compliant steel rolling wheel.
Calibration weight set (50N–500N).
Software Add-Ons:
Batch Processor: Queue 24/7 unattended testing.
API Integration: Connect to MATLAB/Python for custom analytics.
Safety Upgrades:
Explosion-proof enclosure for solvent-resistant testing.
HEPA filtration for particle-sensitive labs.
Calibration Services:
Annual recalibration with NIST-traceable certificate.
Consumables:
10 × Replacement polycarbonate dome panels.
1L Silicone lubricant for high-cycle testing.
Technical Parameters
| Specification | Details |
|---|---|
| Load Range | 50N to 500N (adjustable in 1N increments) |
| Wheel Diameter | 75mm (EN 1569 compliant) |
| Cycle Speed | 1–10 cycles/minute (0.1 cycle resolution) |
| Sample Thickness | 2mm to 50mm (0.1mm resolution) |
| Power Supply | 220V/50Hz (110V/60Hz available) |
| Dimensions (W×D×H) | 600mm × 500mm × 1.200mm |
| Weight | 80 kg (net) |
