Powder Wet Vibrating Screen System For Lithium Battery Material Testing
Standard
ASTM E11: Standard Specification for Woven Wire Test Sieve Cloth and Test Sieves
ISO 3310-1: Test Sieves – Technical Requirements and Testing – Part 1: Test Sieves of Metal Wire Cloth
IEC 62660-3: Secondary Lithium-Ion Cells – Part 3: Safety Requirements
RoHS Compliance(Restriction of Hazardous Substances)
CE Certification(Conformité Européenne)
Product Advantages
Wet Sieving Precision
Sub-10 μm Resolution: Separates nano-scale particles in slurries with 99.5% accuracy.
Anti-Clogging Design: Ultrasonic transducer prevents particle aggregation during wet testing.
Corrosion Resistance
316L Stainless Steel Construction: Withstands acidic/alkaline electrolytes and organic solvents.
IP67 Rating: Fully submersible for easy decontamination.
High-Throughput Processing
4-Layer Sieve Stack: Simultaneous particle size distribution (PSD) analysis in 5 minutes.
Auto-Flush System: Integrates with CIP (Clean-In-Place) protocols for rapid turnover.
Intelligent Control
7” HD Touchscreen: Preprogrammed ASTM/ISO test protocols with customizable dwell times.
Data Integrity: Blockchain-secured results for audit-ready compliance.
Safety First
Explosion-Proof Motor: ATEX-certified for use in inert atmospheres.
Emergency Drain: Solvent-resistant siphon system with gravity-activated cutoff.
Product Features
Variable Frequency Drive: Adjustable vibration (50–3.000 RPM) for optimal particle stratification.
Laser-Guided Leveling: Ensures consistent sieve stack alignment (±0.05° accuracy).
Temperature Control: Built-in Peltier module (-10°C to 60°C ±0.2°C stability).
3D Particle Imaging: Optional microscope adapter for real-time morphology analysis.
Voice-Activated Controls: Hands-free operation during solvent-intensive tests.
Accessories
Sieve Kit:
4x stainless steel test sieves (200mm diameter, 20/50/100/200 μm meshes).
Sieve pan and lid with O-ring seals.
Software Suite:
License key forSieveMaster Pro(Windows/macOS).
1-year free access to cloud-based PSD analytics.
Safety & Maintenance:
Explosion-proof gloves (Class 00. 3 pairs).
Sieve cleaning brush (stainless steel bristles).
Wet Testing Kit:
Solvent-resistant pump (10 L/min flow rate).
5m silicone tubing with quick-release fittings.
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for ASTM/ISO/IEC standards.
Technical Parameters
| Parameter | Specification |
|---|---|
| Sieve Diameter | 200mm, 300mm, 450mm (interchangeable) |
| Mesh Range | 5 μm – 5 mm (ASTM E11 compliant) |
| Vibration Amplitude | 0.5–3.0 mm (adjustable) |
| Power Supply | 100-240V AC, 50/60Hz (universal adapter) |
| Noise Level | <65 dB (A-weighted) |
| Dimensions | 500mm (W) × 450mm (D) × 800mm (H) |
| Weight | 85 kg (net) / 105 kg (gross) |
