Photovoltaic module damp heat test chamber
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standard
IEC 61215: Terrestrial Photovoltaic (PV) Modules – Design Qualification and Type Approval
UL 1073: Standard for Safety for Enclosures for Electrical Equipment
ISO 16750-4: Road Vehicles – Environmental Conditions and Testing for Electrical and Electronic Equipment
CE Certification(Conformité Européenne)
Product Advantages
Extreme Environmental Simulation
85°C ±2°C / 85% RH Control: Replicates 10+ years of tropical aging in 1.000 hours (IEC 61215-compliant).
95% RH Max Humidity: Tests PID resistance and encapsulant degradation under extreme moisture.
Ultra-Stable Performance
±1°C Temperature Stability: Ensures consistent testing across 10.000+ cycles.
≤2°C Uniformity: Patented airflow design eliminates hot/cold spots.
Energy Efficiency
40% Lower Power Consumption: Advanced insulation and heat recovery systems.
ECO Mode: Auto-powers down during stabilization phases.
Safety First
Dual Overload Protection: Thermal cutout and current-limiting circuit breaker.
Door Interlock System: Prevents accidental chamber access during testing.
Smart Diagnostics
AI-Powered Degradation Prediction: Analyzes IV curve shifts and EL imaging data.
Remote Monitoring: 4G/LTE connectivity with SMS/ alerts.
Product Features
Dual-Chamber Design: Isolated wet/dry zones for simultaneous multi-condition testing.
10” Touchscreen HMI: Preloaded IEC/UL test profiles with customizable hold times.
Self-Cleaning System: Automated condensation drainage and chamber drying.
Modular Expansion: Up to 1.500L capacity for full-size PV array testing.
Glovebox Compatibility: Oxygen/moisture control for sensitive electronics testing.
Accessories Included
Testing Kit:
4x universal sample racks (adjustable for batteries/PV modules/PCBAs).
10x humidity sensor calibration capsules.
Software Suite:
License key forEnviroTest Pro(Windows/Linux).
1-year free access to cloud-based test report generator.
Calibration & Safety:
NIST-traceable temperature/humidity logger.
Emergency eyewash station (portable).
Maintenance Kit:
Spare heating elements and refrigerant filters.
Chamber cleaning solution (non-corrosive).
Documentation:
Multilingual quick-start guide (printed + digital).
Compliance certificates for IEC/UL/ISO standards.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | 30°C to 85°C (operational) |
| Temperature Stability | ±1°C (at 85°C setpoint) |
| Temperature Uniformity | ≤±2°C (empty chamber) |
| Humidity Range | 30%–95% RH (non-condensing) |
| Humidity Stability | ±2.5% RH (at 85% RH) |
| Chamber Volume | 500L (standard), expandable to 1.500L |
| Power Supply | 380V/415V 3-phase, 50/60Hz |
| Dimensions | 1.200mm (W) × 1.800mm (D) × 2.000mm (H) |
| Weight | 800 kg (net) / 1.200 kg (gross) |
