Artificial turf wear tester
Standard
FIFA Quality Programme: Exceeds 2015/2016 handbook requirements for artificial turf abrasion resistance testing.
EN 15330-1: European standard for shock absorption and deformation recovery in synthetic sports surfaces.
Product Advantages
1. Unmatched Realism
Dual-Action Abrasion System: Reciprocating rubber-coated discs + particle-embedded rollers simulate realistic athletic wear.
FIFA-Validated Methodology: Mimics cleat impact, sliding, and pivot movements.
2. High-Throughput Testing
Dual-Sample Capacity: Test two 1m × 2m turf strips simultaneously.
12m² Test Area: Industry-leading workspace for large-scale durability mapping.
3. Precision Engineering
Variable Speed Control: 0.1–1.0 m/s adjustable for sprint/jog simulation.
Digital Cycle Counter: Auto-pauses at 3.020/6.020 cycles for intermediate inspections.
4. User-Centric Design
Tool-Free Clamping: Quick-release beams secure turf samples in <60 seconds.
Dutch Craftsmanship: 10+ years of Lisport innovation in every machine.
5. Robust Construction
Corrosion-Resistant Frame: Coated stainless steel + anodized aluminum for 10+ year lifespan.
Floor-Anchored Design: Withstands 1.500kg operational mass without shifting.
Product Features
Abrasion System:
Rubber-Coated Discs: 200mm diameter with 60 Shore A hardness.
Particle Rollers: Interchangeable grit inserts (40/60/80 mesh).
Control Panel:
10” HMI touchscreen with pre-loaded FIFA test protocols.
USB/Ethernet ports for PC connectivity and remote diagnostics.
Safety Systems:
Emergency stop with E-Stop loop monitoring.
Overload protection at 110% of rated capacity.
Software Suite:
TurfDur Pro™: Auto-calculates abrasion resistance (FIFA stars) and fiber loss.
Cloud Sport: Remote monitoring for global R&D teams.
Illumination:
Adjustable LED array (3.000–6.500K color temperature).
Anti-glare diffusers for operator comfort.
Accessories & Options
Standard Kit:
2 × Abrasion discs with rubber coating.
4 × Particle roller inserts (40/60/80 mesh).
Quick-release sample clamps.
Software Add-Ons:
Batch Processor: Queue 24/7 unattended testing.
API Integration: Connect to MATLAB/Python for custom analytics.
Calibration Services:
Annual recalibration with NIST-traceable certificate.
Custom Upgrades:
Climate chamber integration (-20°C to +60°C).
Automated fiber loss measurement system.
Consumables:
10L Replacement abrasive particles.
1L Silicone lubricant for high-cycle testing.
Technical Parameters
| Specification | Details |
|---|---|
| Test Area | 12m² (1m × 12m) |
| Speed Range | 0.1–1.0 m/s (adjustable in 0.01 m/s steps) |
| Cycle Capacity | 1–10.000 cycles (pre-settable intervals) |
| Power Supply | 380V/32A/50Hz (3-phase) |
| Dimensions (W×D×H) | 6.500mm × 2.000mm × 1.800mm (folded) |
| Expanded Footprint | 8.000mm × 3.000mm × 2.200mm (operational) |
| Weight | 1.500 kg (net) |
