PV Hail Impact Tester
Standard Compliance
IEC 61215: Mechanical load testing for terrestrial photovoltaic modules.
UL 61730: Safety standards for photovoltaic modules under extreme weather conditions.
ASTM E1886: Impact resistance testing for building envelopes (adapted for PV applications).
IEC TS 63057: Hail impact simulation protocols for concentrated solar power systems.
Product Advantages
Precision Engineering:
High-speed pneumatic system delivers repeatable impact energies (±2% accuracy).
Adjustable ice ball diameter (25mm–75mm) to simulate diverse hailstone sizes.
Safety First:
Enclosed testing chamber with transparent polycarbonate shielding.
Emergency stop function and over-pressure protection.
User-Friendly Operation:
7-inch touchscreen HMI with multi-language support (English/Spanish/German/Chinese).
Pre-programmed test modes for IEC/UL/ASTM standards.
Customizable Solutions:
Optional environmental chamber (-40°C to +85°C) for extreme temperature testing.
Modular design for easy integration into existing QC lines.
Product Features
Dual-Station Testing: Simultaneous evaluation of two PV modules for accelerated workflows.
High-Speed Imaging: Built-in 1000fps camera captures impact dynamics for post-test analysis.
Automated Control:
Programmable trajectory system for precise ice ball launch angles (0°–90°).
Real-time data logging (force, velocity, deformation) via USB/Ethernet.
Robust Construction:
Stainless steel frame with anti-vibration mounting.
Low-noise operation (<65 dB) for laboratory environments.
Accessories Included
100x Ice Balls(25mm/35mm/50mm/75mm mix)
Sample Clamping Kit(adjustable for frameless/framed modules)
Software Suite:
Real-time data acquisition & analysis tool.
Test report generator (PDF/Excel export).
Spare Parts Kit:
2x pneumatic nozzles, 5x O-rings, 1x calibration tool.
User Manual:
Multilingual guide (printed + digital copy).
Technical Parameters
| Parameter | Specification |
|---|---|
| Impact Energy Range | 0.5 J – 50 J (adjustable) |
| Ice Ball Diameter | 25 mm, 35 mm, 50 mm, 75 mm (standard) |
| Test Temperature Range | -40°C to +85°C (with optional chamber) |
| Sample Size | Max. 2200mm × 1400mm (dual-station) |
| Power Supply | 220V/380V, 50/60Hz, 3-phase |
| Air Compressor Requirement | 0.6–0.8 MPa, 1.2 m³/min |
| Dimensions (L×W×H) | 3500mm × 2000mm × 2500mm |
