Thrust Bearing Rolling Friction and Wear Testing Machine
Applicable Standards:
ASTM D3702
ASTM G99
ASTM G77
ISO 18535
Product Advantages:
Simulates Real-World Conditions: Allows testing under controlled load, speed, temperature, and lubrication conditions relevant to actual thrust bearing operation.
Quantifies Friction and Wear: Provides objective, measurable data on key performance indicators.
Enables Material and Lubricant Comparison: Facilitates the evaluation and selection of the best materials and lubricants for specific applications.
Predicts Bearing Life: Wear rate data can be used to estimate the expected lifespan of thrust bearings.
Supports Design Optimization: Provides critical feedback for improving bearing designs to reduce friction and wear.
Standardized Testing: Allows for testing according to recognized industry standards.
Technical data:
Maximum radial load: 5 kN
Maximum spindle diameter: 5 to 30 mm
Spindle taper: DIN 69871A, ISO 50 taper
Rotary motion:
Speed: 0 to 2000 rpm
Continuous torque: 56.4 Nm
Peak torque: 136 Nm
Oscillating motion:
Ranges: variable 0 to +/-20°
Frequency: 0.001 to 1 Hz
Axial motion:
Maximum thrust: 5 kN Stroke: 0 to 30 mm Frequency: 0.001 to 1 Hz kN
Stroke: 0 to 30 mm
Frequency: 0.001 to 1 Hz
Send product request
